1-35
Cisco 7200 VXR Installation and Configuration Guide
OL-5013-09
Chapter 1 Cisco 7200 VXR Product Overview
Field-Replaceable Units
Figure 1-17 C7200-I/O-FE—With MII and RJ-45 Fast Ethernet Receptacles (Version 1)
1 Temperature sensor 8 PC Card slots
2 Midplane connectors 9 Optional Fast Ethernet interface (MII port and
RJ-45 port)
3 Flash SIMM (U99) 10 LEDs
4 Boot ROM (U20) 11 CPU reset button
5 NVRAM (U41) 12 Auxiliary port
6 Temperature sensor 13 Console port
7 Captive installation screw
84531 AUX
CONSOLE PCMCIA EJECT SLOT 0
SLOT
1
FE MII
FAST ETHERNET INPUT/OUTPUT CONTROLLER
RJ45
CPU RESET
M II E N
R J4 5
E N R J4 5
LIN K
I/O P W R
O K
ENABLED
8
10
7
11
13 12
1
4
3
5
6
9
2
