1-16
Cisco 7200 VXR Installation and Configuration Guide
OL-5013-09
Chapter 1 Cisco 7200 VXR Product Overview
Field-Replaceable Units
Figure 1-6 NPE-G1
Table 1-4 lists the NPE-G1 memory specification, and Table 1-5 lists the factory-installed SDRAM
configurations and their product numbers.
Primary cache 32 KB (16 KB
instruction,
16 KB data)
— Motorola Freescale 7448
processor, internal cache U30
Secondary
cache 1 MB — Motorola Freescale 7448
secondary cache U30
Table 1-3 NPE-G2 SDRAM Configuration—Configurable Memory Only
Total SDRAM SDRAM Bank Quantity
1 GB S1 1-GB DIMM
Table 1-2 NPE-G2 Memory Specifications (continued)
Memory Type Size Quantity Description
Component Location
on the NPE-G2 Board
1 Midplane connectors 6 Boot ROM
2 Flash memory 7 NVRAM
3 Temperature sensor 8 DIMM 2
4 Processor 9 Temperature sensor
5 Keying post 10 DIMM 1
66435
G I G A B I T E T H E R N E T 0 / 1
R J 4 5 G B I C E N R X T X
L I N K
CONSOLE AUX
G I G A B I T E T H E R N E T 0 / 1
R J 4 5 G B I C E N R X T X
L I N K
G I G A B I T E T H E R N E T 0 / 1
R J 4 5 G B I C E N R X T X
L I N K C P U R E S E T
C O M PA C T F L A S H POWER ON
S L O T A C T I V E NETWORK PROCESSING ENGINE - G1
5
4
3
6
8
7
9
10
1
2
