Preparation
Attaching the Speakers
To attach/detach the loudspeakers, please see diagrams as
indicated.
Speakers' Connection
• Connect the right speaker to terminal R, with the red wire to +
and the black wire to —.
• Connect the left speaker to terminal
L,
with the red wire to +
and the black wire to —.
• Clip the stripped portion of the speakers wire as shown.
Batteries
FortheSet (notsupplied)
• Open the battery compartment and insert six batteries, type
R20, UM-1 or D-cells (preferably alkaline).
• Remove the batteries if they are dead or the set is not to be used
for a long time.
Forthe Remote Control (supplied)
• Open the battery compartment and insert two batteries, type
RB, UM-3 or AA-cells (preferably alkaline).
• Remove the batteries if they are dead or the remote control is not
to be used for a long time.
Adjusting the Operating Voltage
Before connecting the AC power cord to a wall outlet, make
sure that the voltage selector at the rear of the system is set
to the local power line voltage. If not, reset the selector
before connecting to the wall outlet.
