4 Pet Immune SAW PIR Motion Sensor w ith Lithium Battery Installation Instructions
To trip the sensor:
1. Remove the PIR from its mounting plate activating the
tamper switch.
2. Exit the panel’s programming mode.
3. Return the PIR to its mounting plate.
Final Testing
Final testing should be done to verify radio signal integrity and
confirm control panel programming and response. The actual
transmitter range can be determined by performing a sensor
test as follows:
1. After the sensor has been mounted, remove it from its
mounting plate and activate the tamper switch to start the
walk test mode.
2. Replace the sensor in its mounting plate.
3. Place the control panel in test mode. Move across the
detection pattern until the sensor’s LED turns on. STOP
your motion.
4. Listen for the appropriate system response. If the system
does not respond, proceed to “Troubleshooting” below.
Troubleshooting
Use the following guidelines if the system does not respond
correctly when the sensor is activated.
• Check programming and reprogram sensor into panel if
necessary.
• Move the sensor to another location and test for correct
response.
To relocate a sensor:
1. Test the sensor a few inches from the original position.
2. Increase the distance from the original position and retest
until an acceptable location is found.
3. Mount the sensor in the new location.
4. If no location is acceptable, test the sensor as described
below:
Test a known good sensor at the same location.
If the system does not respond, avoid mounting a sensor
at that location.
If the replacement sensor functions, return the problem
sensor for repair or replacement.
Specifications
Compatibility Simon®, Concord ™, Concord Express,
SuperBus® 2000 RF Receiver, Quik Bridge®
1 & 2 Channel and Loop Receivers
Pow er source 1 AA Lithium battery; Part # 60-619 (six
batteries per pack)
Typical battery life 4-6 years at 68° F
Transmitter frequency 319.5 MHz
Operating temperature 32° to 120° F (0° to 49° C) Non-pet
applications
60° to 120° F (16° to 49° C) Pet applications
Storage temperature
range -30° to 140° F (-34° to 60° C)
Maximum humidity 90% Relative Humidity non-condensing
Dimensions 2.9 in. (7.4 cm) x 2.4 in. (6.1 cm) x 1.9 in. (4.8
cm) (L x W x H)
Regulatory information
Manufacturer UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112-6943,
USA
FCC compliance These devices comply w ith part 15 of the FCC
rules. Operation is subject to the follow ing tw o
conditions:
These devices may not cause harmful
interference.
These devices must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved
by UTC Fire & Security can void the users’
authority to operate the equipment.
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.interlogix.com/customer-
support
© 2012 UTC Fire & Security Americas Corporation, Inc.
Interlogix is part of UTC Climate Controls & Security, a unit of
United Technologies Corporation.
All rights reserved.
