4. Insert the expansion plug into the hole just drilled and make
sure that the top end of the plug does not protrude from the
wall. Align the mounting plate over the hole and use a bolt
to secure the mounting plate to the wall. If no test trans-
mitter is used, go to step #10.
5. Before tightening the bolt, twist the mounting plate to posi-
tion the DV1215 drill pattern hole (see drawing in Section
3.2) where the cable is to be routed (in most cases, at the
bottom). Check for proper horizontal/ vertical alignment of
the DV1201/DV1221.
6. Mark the DV1215 mounting hole using the felt pen. Position
the mounting plate so that the marked spot is over the
DV1215 mounting hole (see drawing in Section 3.2).
7. Drill a hole using a 1/2” diam. drill on the spot marked. Be
sure the expansion plug is flush with or below the surface
of the wall.
8. Insert the DV1215 expansion plug into the hole you have
just drilled, ensuring that the top end of the plug does not
protrude from the wall. Place the DV1215 test transmitter
over the hole and secure using the bolt provided with the
expansion plug.
9. Ensuring that the DV1215 does not touch the mounting
plate, tighten the bolt. To provide proper seating of the
plug, hit the bolt’s head (carefully avoiding the DV1215) a
few times with a hammer and tighten the bolt once more.
NOTE: At the first service visit after the installation, tighten
all bolts once more to compensate for inevitable material
expansion in both wall and plug.
10. After completion of the mounting of the mounting plate on
concrete, install the DV1201/DV1221 detector according to
the description in 3.3.
TABLE 2 - RECOMMENDED SENSITIVITY SETTINGS FOR
A SAFE WITH ONE DV1201 OR DV1221 DETECTOR
Planning the Protection of an Automatic Cash Dispensing
Unit (ATM) and a Night Depository Box
For both units, use the DV1221 to filter out
noise generated by normal operation of the
units. The DV1221 can be mounted directly
on the surface of the structure.
• Automatic Cash Dispensing Unit -
Protection is planned exactly as for a safe.
Note: The DV1221 is not designed for use
on concrete. If the ATM has a concrete
body, a DV1201 can be mounted on the
outside surface or a DV1221 can be
mounted on the inside metal surface.
• Night Safe Deposit Box - Protection is
planned exactly as for a safe. Insulate
the chute and the landing place with rub-
ber insulating material to muffle the
noise created by the cash boxes as they
are deposited.
TABLE 3 - RECOMMENDED SENSITIVITY SETTINGS ON A
CASH DISPENSING UNIT (ATM) AND NIGHT DEPOSITORY
WITH ONE DV1221 DETECTOR
4.0 CABLE REQUIREMENTS
TABLE 4 - ADVISOR X SYSTEM CABLE
REQUIREMENTS
4.1 WS300 Cable Preparation Instructions
The Aritech WS300 High Security Cable is specially designed
to provide electrically protected cabling in a UL Complete
Mercantile Safe System. The cable consists of double circuit
shields that enclose all conductors. When wired per the Wiring
Diagrams in Sections 4.0 and 7.0, the WS300 Cable complies
with the description of electrically protected cable in UL 681.
The two aluminum shields that wrap the eight-conductor cable
are isolated from each other. Each shield is electrically con-
ductive to a drain wire (stranded cable, no insulation). In the
preparation of the cable for connection to the DV1201/DV1221
detector and at the control panel, the shields and correspond-
ing drain wires must be kept isolated. A special cable prepara-
tion procedure is described below.
5
Thickness Maximum Method of Attack
of Steel Cubic Ft.
Torch Drilling Mechanical
Over 1/4” but 12 Cu ft:
under 1”
DV1201 3 3 3
DV1221 2 2 2
Over 1” 52 Cu ft:
DV1201 3 3 3
DV1221 1 1 1
Note: These settings are only guidelines. All final settings are to be made
following the steps in Section 5.0.
DV1221
DV1221
Note: These settings are only guidelines. All final settings are to be made fol-
lowing the steps in Section 5.0.
Thickness Maximum Method of Attack
of Steel Cubic Ft.
Torch Drilling Mechanical
Over 1/4” but 12 Cu ft:
under 1”
DV1221 2 2 2
Over 1” 52 Cu ft:
DV1221 1 1 1
Number of
Conductors
Multi Sensor System
with Individ. Indication
Feature Stand-alone DV1208
Power 2 2
Alarm form C 2-4 2-4
Tamper 2 2
Test in 1 1
Test out (LED) - 1
separate
home run
