• Ensure the Day/Night and Walk Test inputs are
floating/open, so the DD669-U unit is in the Day mode and
the Walk Test mode is off.
The detector will switch the microwave section off for 3 minutes
after a dual alarm. The detector is in PIR only during this timer.
LED indication
Red [1
]
Green [1] Yellow [1] Alarm relay To rese
t
Start up Closed Automatically after 45 s
Low voltage Open
(Alarm) Apply correct voltage
PIR intruder
alarm Automatically after 3 s
Microwave
intruder alarm Automatically after 3 s
(Dual) motion
intruder alarm Open
(Alarm) Automatically after 3 s
Latched PIR
(Memory) Switch to Night mode
Continuously on Normal blinking (1 Hz)
[1] Tri-color LED.
Specifications
Detector Dual
Range diameter (selectable) 20 ±0.5 m (65 ft. 7 in. ± 1 ft. 7 in.)
or 12 ±0.5 m (39 ft. 4 in. ± 1 ft. 7 in.)
Viewing angle (selectable) 360 degrees or 180 degrees
Optical 2 x 9 curtains
Microwave frequency 5.8 GHz
Max microwave output at 1 m 0.003 μW/cm²
Memory Yes
Input power 9 to 15 V
For UL/cUL installations: 10 to 15 V
Peak-to-peak ripple 2 V (at 12 V
Detector start-up time 45 s
Normal current 12 mA
For UL/cUL installations: 0.144 W
Alarm current 10 mA
Maximum current 15 mA
Mounting height 2.5 to 5.0 m (8 ft. 2 in. to 16 ft. 5 in.)
Target speed range 0.3 to 3.0 m/s (1 ft./s to 9 ft. 10 in./s)
Alarm (NC) / Tamper relay
characteristic 80 mA, 30 V
Pry-off tamper (not evaluated
by UL/cUL) Optional
Alarm time 3 s
Operating temperature 0 to 49°C (32 to 120°F)
Dimensions (  x H) 138 x 92 mm (5.43 in. x 3.62 in.)
Relative humidity max. 95% (UL/cUL installations)
Weight 255 g (9 oz.)
IP/IK rating IP30 IK02
Certification and compliance
Manufacturer UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112-6943, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
FCC Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna
• Increase the separation between the equipment
and receiver
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV
technician for help
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
FCC ID: YFYDD669-U
IC This Class B digital apparatus complies with Canadian
ICES-003.
UL/cUL All wiring is to be installed according to National
Electrical Code, NFPA70 and CSA C72.1, Canadian
Electrical Code Part 1, Safety Standard for Electrical
Installations
The product must be connected to a Listed Burglar
System compatible control unit or power supply, that
provides a minimum of 4 hours standby power and has
a voltage output between 10 and 15 VDC.
Perform walk test at least one per year.
Use only a listed power-limited supply.
