IC Realtime 1.3 Megapixel 18X PTZ Network Camera with Up-to 300 ft IR (ICIPMP1808IR) User Manual

Page 18

Move the cursor to SITE INFORMATION and then click confirm button.
z

ADDR TYPE: System supports software address only.

ADDR-SOFT: It is to display speed dome software address. Please use the left/right button on the

keyboard or in the speed dome terminal menu to set. The value ranges from 1 to 255.

BACK: Go back to the previous menu.

EXIT: Log out system menu.

4.4.2 Display

Setting

Before the operation, please make sure you purchased camera supports zoom function.

Move the cursor to DISPLAY SETTING and then click confirm button, you can go to the third submenu.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set. After completed
setup, please click save button to save current setup.
z

PRESET: Display dome preset title or not. Please use the left/right button on the keyboard or in the

speed dome terminal menu to set. You can go to Function Setup->Preset section to set corresponding
preset value and preset title.

AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the

keyboard or in the speed dome terminal menu to set

TIME DISP: Display dome system time or not. Please use the left/right button on the keyboard or in the

speed dome terminal menu to set.

POSITION: Display the angel between the benchmark and then current location. Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

ZOOM DISP: Display speed dome optical zoom speed or not.

INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options: ℃/F/Off.

Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

TITLE DISPLAY: Here you can set to display speed dome position information and etc. You can use the

speed dome control terminal to set the detailed title information. Please use the left/right button to set.

BACK: Go back to the previous menu.

EXIT: Log out system menu.

4.4.3 Camera

Setting

Before the operation, please make sure your camera supports the corresponding function.

PRESET ：

AZIMUTH DISP ：

TIME DISP ：

POSITION ：

ZOOM DISP ：

INSIDE TEMP ：

TITLE DISP ：

BACK EXIT

WB SETTING

EXPOSURE SETTING

DAY/NIGHT SETTING

FOCUS SETUP

IMAGE ADJUST

ZOOM SPEED

APERTURE :

APERTURE RESTRAIN: 8

DEFOG SETTING

BACK EXIT
