ADDR :001-S

BAUD RATE :9600

PARITY :NONE

SOFTWARE :V1.02.0.R

BACK EXIT

SYSTEM SETTING

DISPLAY SETTING

CAMERA SETTING

FUNCTION SETTING

IR LIGHT SETTING

EXIT

Note:
z

ERR means current setup is invalid.

z

Please make sure all the cable connections are right.

4.2 Self-diagnosis System Information




After installation, please connect speed dome to power. The system goes on a self-diagnosis, and then it
pops up the above interface to show the system information.

The above interface disappears after speed dome received the first command (or the display time lasts for
20 seconds.)
z

ADDR: Here you can view dome address information. For example, 001-S, 1 is the address number, –S

is software address mode.

z

Baud rate: Dome communication baud rate.

z

Parity: Communication parity bit format.

z

Software: Dome PTZ software version.

When you are using the control keyboard or the matrix host to control the device, please make sure

the control parameter of the keyboard or the matrix host is the same with the speed dome OSD

(including address, baud rate, parity). Please make sure the cable connection is OK.

4.3 Main Menu

You can open the IP dome menu via control keyboard, matrix, or speed dome control terminal.




z

SYSTEM

SETTING:Display speed dome system information, address information. Here you can set

north direction, language, factory default setup, reboot and so on.

z

DISPLAY SETTING: Display dome preset title, azimuth display, time, direction, dome internal

temperature, title information, zoom information and etc.

z

CAMERA SETTINGS:Set dome white balance, camera parameter, day/night setup and etc.

z

FUNCTION SETTING: Set preset, pan, auto scan, auto tour, pattern, idle function, time task and

privacy mask function.

z

IR LIGHT SETTING: Set dome IR sensitivity, IR control principle, medium and far light bright, far light

bright, IR light compensation and etc.

z

EXIT: Log out the system menu.
