27

TIME TASK :OFF

START TIME :06H 00M

END TIME

: 10H 00M

TASK ACTION : SCAN

PRESET : 001

SCAN : 001

TOUR : 001

PATTERN : 001

SAVE

BACK

EXIT

IR SENSITIVITY: 4(1-6)

SWITCH ZOOM: 6(2-10)

HEIGHT: 5(1-10)

IRLIGHT CTRL: ZOOM PRI (HEIGHT PRI, MANUAL)

NEAR LIGHT: 50(0-100, INTERVAL=5)

FAR LIGHT: 50(0-100, INTERVAL=5)

IRLIGHT COMP: 3(1-5)

• EXIT: Log out system menu.

4.4.4.8 Time Task








• TIME TASK: Schedule task allows the speed dome to implement corresponding setup during the

specified time. There are two options: on/off. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.

• START TIME: Here you can set the task begin time. Move the cursor to current item and then click

confirm button to set the time. Please use the up/down button to set the detailed value and then use
left/right button to go to the next setup item. After you completed the setup, please click confirm
button to exit start time setup and then move the cursor to the SAVE button to save current setup.

• END TIME: Here you can set the task end time. Move the cursor to current item and then click

confirm button to set the time. Please use the up/down button to set the detail value and then use
left/right button to go to the next setup item. After you completed the setup, please click confirm
button to exit end time setup and then move the cursor to the SAVE button to save current setup.

• TASK ACTION; The option here includes: none/tour/scan/preset/patter. Please use left/right button

to set.

• PRESET: The speed dome will go to the selected preset at the specified time if you select the time

task as preset. The value ranges from 1 to 80.

• SCAN: The speed dome will go to the selected scan at the specified time if you select the time task

as scan. The value ranges from 1 to 5.

• TOUR: The speed dome will go to the selected preset at the specified time if you select the time task

as tour. The value ranges from 1 to 8.

• PATTERN: The speed dome will go to the selected pattern at the specified time if you select the time

task as pattern. The value ranges from 1 to 5.

• SAVE: After you completed the above setup, you need to move the cursor here and then click

confirm button to save current time setup.

• BACK: Go back to the previous menu.
• EXIT: Log out the system menu.

4.4.5

IR Light Setup





Move the cursor to highlight IR LIGHT SETTING button and then click confirm button.
z

IR SENSITIVITY: Here you can enable the IR light sensitivity function.
