IC Realtime 600TVL / 650TVL 23X High Speed PTZ Camera with 250' IR - Manual (Page 22)

15
ADDR ：001-H
BAUD RATE ：9600
PARITY ：NONE
PROTOCOL ： PELCO-P
MODEL ：SD66XX
TEMP : 032℃
SOFTWARE ：V1.04.3
BACK
EXIT
SYSTEM INFORMATION
DISPLAY SETTING
CAMERA SETTING
FUNCTION SETTING
IR LIGHT SETTING
ALARM SETTING
EXIT
The above diagram illustrates the overall structure of the speed dome setup menu.
Note:
z
ERR means current setup is invalid.
z Please make sure all the cable connections are right.
4.2 Self-diagnosis System Information
After installation, please connect speed dome to power. The system goes on a self-diagnosis, and then it
pops up the above interface to show the system information.
If there is anything wrong during the self-diagnosis, system pops up error code.
The above interface disappears after speed dome received the first command (or the display time lasts for 4
minutes.)
z
ADDR: Here you can view dome address information. For example, 001-H, 1 is the address number, -H
is hard address mode. –S is software address mode.
z Baud rate: Dome communication baud rate.
z Parity: Communication parity bit format.
z Protocol: Current communication protocol.
z Model: Dome type.
z Temperature: Current dome internal temperature.
z Software: Dome PTZ software version.
4.3 Main Menu
You can open the IP dome menu via control keyboard, matrix, or speed dome control terminal.
z SYSTEM INFORMATION：Dome self-diagnosis information, address information, system time setup,
set north direction, language, factory default setup, reboot and so on.
z DISPLAY INFORMATION: Display dome preset title, azimuth display, time, direction, dome internal
temperature, dome external temperature information.
