Page 23
16
INITIAL INFORMATION
ADDR INFORMATION
SYSTEM TIME SETTING
SET NORTH
LANGUAGE : ENGLISH
PTZ AUTO STOP
FACTORY DEFAULT
RESTART
BACK
EXIT
z
CAMERA PARAMETERS
：Display dome white balance setup, exposure setup, day/night setup, focus
setup.
z
FUNCTION SETTING
： Set preset, pan, scan, auto cruise, pattern, idle motion, time task and privacy
mask function.
z
IR LIGHT SETTING: Set dome IR sensitivity, switch rate, reference height, IR control principle, medium
and far light bright, far light bright, IR light compensation and etc.
z
ALARM
SETTING ：Set dome alarm number, action, contact, preset, scan, cruise, replay out, reset
delay, save setup and etc.
z
EXIT
： Log out the system menu.
4.4 Menu Operation
In the speed dome main menu, you can use the left/right button on the keyboard or in the speed dome
terminal menu to configure the system menu. Before setup, please move the cursor to the current item you
want to configure.
z
In main menu, please click confirm button to go to the sub menu or use left/right key to configure setup.
z
Use up/down button to select back option and then click confirm button to go back to the previous menu.
z
Use up/down button to select exit option and then click confirm button to log out system menu.
z
All setup here will not lose when encounter power failure.
4.4.1
System Information
z
INITIAL INFORMATION: Move the cursor to INITIAL INFORMATION and then click confirm button to go
to the third submenu.
z
ADDR INFORMATION: Move the cursor to SITE INFORMATION and then click confirm button to go to
the third submenu.
z
SYSTEM TIME SETTING: Move the cursor to SYSTEM TIME SETTING and then click confirm button
to go to the third submenu.
z
SET NORTH DIRECTION: Set dome benchmark direction so that you can know the angel between the
benchmark and then current location. Please move the cursor to the option and then click confirm
button until you see O.K. Now you have set north direction.
z
LANGUAGE: The dome menu language. There are several languages for you to select. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
z
PTZ AUTO STOP: The PTZ stop the corresponding operation once it reaches the time you specified
here. The option includes: close\5S\10S\15S\20S\25S\30S and etc. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
