18






Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu. Please
use the left/right button on the keyboard or in the speed dome terminal menu to set. After completed setup,
please click save button to save current setup.
z

PRESET TITLE: Display dome preset title or not. Please use the left/right button on the keyboard or in

the speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.

z

AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the

keyboard or in the speed dome terminal menu to set

z

TIME DISP: Display dome system time or not. Please use the left/right button on the keyboard or in the

speed dome terminal menu to set.

z

POSITION: Display the angel between the benchmark and then current location. Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

z

ZOOM DISP: Display speed dome zoom speed or not. Please use the left/right button on the keyboard

or in the speed dome terminal menu to set.

z

INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options:

℃/F/Off.

Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

OUTSIDE TEMPERATURE AND HUMIDITY: Display dome external temperature and humidity. There

are three options:

℃/F/Off. Please use the left/right button on the keyboard or in the speed dome

terminal menu to set.

z

IDLE TIME: The option includes close/1/2/3/4/5min. The system will exit the menu automatically once

there is no menu operation during the time you specify here. Close means always show the menu.

z

BACK: Go back to the previous menu.

z

EXIT: Log out system menu.

4.4.3 Camera

Setting








Move the cursor to CAMERA SETTING and then click confirm button, you can go to the submenu.
z

WHITE BALANCE SETUP: Move the cursor to current option and then click confirm button, you can go

to the third menu.

z

EXPOSURE SETTING: Move the cursor to current option and then click confirm button, you can go to

the third menu.

PRESET TITLE :ON

AZIMUTH DISP :ON

TIME DISP :OFF

POSITION :OFF

ZOOM DISP :OFF

INSIDE TEMP :℃

OUTSIDE T&H :OFF

IDLE TIME : 1 Min

TITLE DISP :OFF

BACK

EXIT

WB SETTING

EXPOSURE SETTING

DAY/NIGHT SETTING

FOCUS MODE :AUTO

FOCUS LIMIT : 30CM

ZOOM SPEED : 08

DIGITAL ZOOM : OFF

APERTURE : 09

NEXT PAGE

BACK

EXIT
