19

z

DAY/NIGHT: Set day/night mode. Move the cursor to current option and then click confirm button, you

can go to the third menu. There are three options: auto/manual/off. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.

z

FOCUS MODE: There are two modes: Manual/Auto. Please use the left/right button on the keyboard or

in the speed dome terminal menu to set.

z

ZOOM SPEED; The zoom speed value ranges from 1 to 8. The bigger the value, the faster the speed.

Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

DIGITAL ZOOM: There are two options: on/off. Please use the left/right button on the keyboard or in the

speed dome terminal menu to set.

z

APERTURE: It is to adjust the lens to achieve clear video. The value ranges from 1 to 16. Please use

the left/right button on the keyboard or in the speed dome terminal menu to set.

z

NEXT PAGE: It includes the following options: picture flip, freeze function, camera factory default setup,

camera restart. Please use the left/right button on the keyboard or in the speed dome terminal menu to
set.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.

4.4.3.1 White Balance Setup




Move the cursor to WHITE BALANCE MODE and then click confirm button, you can go to the submenu.
z

WHITE BALANCE MODE: Set white balance adjustment mode. There are two modes: auto/manual.

Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

R GAIN: Before you set R GAIN option, please note the mode shall not be auto. The value ranges from

000 to 254. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

B GAIN: Before you set B GAIN option, please note the mode shall not be auto. The value ranges from

000 to 254. Please use the left/right button on the keyboard or in the speed dome terminal menu to set.

z

BACK: Go back to previous menu.

z

EXIT: Log out system menu.


4.4.3.2 Exposure Setting







z

AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris priority)/TV

(shutter priority). Please use the left/right button on the keyboard or in the speed dome terminal menu to
set.

o

Auto: It becomes valid after you set the exposure compensation, backlight compensation
(BLC), slow shutter, wide dynamic region (WDR).

WB MODE : AUTO

R GAIN : 001

B GAIN : 001

BACK

EXIT

AE MODE : AUTO

GAIN SETTING : 02

SHUTTER : 1/50

IRIS SETTING : 11

EXPOSURE COM : 08

SLOW AE : 01

SLOW SHUTTER ON

BLC : OFF

WDR ENBALE : OFF

BACK

EXIT
