7
BATTERY & CHARGER BATTERY & CHARGER
HMXP1004 3S LiPo CHARGER SPECIFICATIONS
Input voltage: 12V DC
Battery types, # cells: 3 lithium-polymer cells connected
in Series (11.1V LiPo)
Charge termination: Voltage detection
Minimum battery capacity: 800mAh
Status indicator: two LEDs
Input connectors: polarized DC power jack for DC input
Output connectors: one balance plug
Case size: 1.8 x 1 x 2.6 in [45 x 25 x 66mm]
Weight: 1.3 oz [41g]
GPMP0413 BATTERY SPECIFICATIONS
Capacity: 1050mAh
Number of Cells in Series: 3
Rated Voltage: 11.1V
Max. Charge Voltage: 12.6V
Min. Discharge Voltage: 8.25V
Ma ximum Recommended
Charge Current: 1050 mA
Co nt. Discharge Current: 14.25A (15C)
Pack Dimensions: 2.2 x 1.26 x 1.1 in
[56 x 32 x 28mm]
Weight: 3.42 oz [97g]
