MM II 15
 Sx and Sy are the X and Y coordinate signs. 1 is positive and 0 is negative. In
absolute coordinates, the sign is always positive. In relative coordinates, the sign
can be positive or negative.
 T is the Tablet Identifier. Your choice of 1 or 0. Command controlled.
 PR is the proximity bit. 0 is in-prox and 1 is out-of-prox.
 PH is the phasing bit, which is always 1.
 X0, X1, etc. and Y0, Y1, etc. are the X and Y coordinate bits.
ASCII BCD Report Format
The ASCII BCD format depends on the coordinate system and resolution:
Resolution Absolute Coordinates Relative Coordinates
1 to 508 lpi (20 lpmm)
1000 lpi or 40 lpmm XXXX, YYYY, F
XXXXX, YYYYY, F S0XXX, S0YYY, F
S00XXX, S00YYY, F
