Mixing cups (GPMR8056)
❏
Hobbico Duster ™ can of compressed air (HCAR5500)
❏
Panel Line Pen (TOPQ2510)
❏
Rotary tool such as Dremel ® with cutoff wheel
❏
Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
❏
Builder’s Triangle Set (HCAR0480)
❏
AccuThrow ™ Defl ection Gauge (GPMR2405)
❏
Hobbico 12 Volt DC power supply (HCAP0250)
IMPORTANT BUILDING NOTES
• When you see the term test fi t in the instructions, it
means that you should fi rst position the part on the assembly
without using any glue, and then slightly modify or custom
fi t the part as necessary for the best fi t.
• Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the
instructions will make a recommendation.
• Whenever just epoxy is specifi ed you may use either
30-minute (or 45-minute) epoxy or 6-minute epoxy. When
30-minute epoxy is specifi ed it is highly recommended that
you use only 30-minute (or 45-minute) epoxy, because you
will need the working time and/or the additional strength.
• Photos and sketches are placed before the step they
refer to. Frequently you can study photos in following steps
to get another view of the same parts.
• Should covering repairs be required, use Top Flite ®
MonoKote ® . MonoKote is packaged in six-foot rolls, but some
hobby shops also sell it by the foot. If only a small piece of
MonoKote is needed for a minor patch, perhaps a fellow
modeler would give you some. MonoKote is applied with a
model airplane covering iron, but in an emergency a regular
iron can be used. A roll of MonoKote includes full instructions
for application. Following are the colors used on this model and
order numbers for six foot rolls.
Jet White – TOPQ0204
Metallic Teal – TOPQ0409
Metallic Plum – TOPQ0403
Metallic Platinum – TOPQ0408
• The stabilizer and wing incidences and motor thrust
angles have been factory-built into this model. However,
some technically-minded modelers may wish to check these
measurements anyway. To view this information visit the web
site at www.greatplanes.com and click on “Technical Data.”
Due to manufacturing tolerances which will have little or no
effect on the way your model will fl y, please expect slight
deviations between your model and the published values.
ORDERING REPLACEMENT PARTS
Replacement parts for the Great Planes Reactor Bipe 3D EP
are available using the order numbers in the Replacement
Parts List that follows. The fastest, most economical service
can be provided by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico ® web site at
www.hobbico.com. Choose “Where to Buy” at the
bottom of the menu on the left side of the page. Follow the
instructions provided on the page to locate a U.S., Canadian
or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa
® or MasterCard ®
number and expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment is by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason contact Product
Support by e-mail at [email protected],
or by telephone at (217) 398-8970.
Replacement Parts List
GPMA3137 Fuselage
GPMA3138 Top
Wing Set
GPMA3139 Lower Wing Set
GPMA3140 Vertical Fin Set
GPMA3141 Stabilizer/Elevator Set
GPMA3142 Wing Struts
GPMA3143 Landing Gear
GPMA3144 Canopy
GPMA3145 Wheel
Pants
GPMA3146 Battery Hatch
GPMA3147 Cowl
GPMA3148 Cabane
Pylon
GPMA3149 Motor “X” Mount
GPMA3150 Decal Sheet
