1 You must assemble the model according to the

instructions Do not alter or modify the model, as doing so
may result in an unsafe or unflyable model In a few cases

the instructions may differ slightly from the photos In those
instances the plans and written instructions should be
considered as correct.

Terns in parentheses (GPMQ4243) are suggested part
numbers recognized by distributors and hobby shops and
are listed for your ordering convenience GPM is the Great

Planes brand, TOP is the Top Flite brand, and HCA is the
Hobbico" brand.

2. Take time to build straight, true and strong.

3. Use an R/C radio system that is in first class condition,
and a correctly sized engine and components (fuel tank,
wheels, etc ) throughout your building process.

D 4 Channel radio with 5 servos and a Y-harness
D 3 5 - 4 6 2-stroke or 40 - 52 4-stroke engine
D 6oz Fuel tank (GPMQ4102)
D (2) 2-1/2" Wheels (GPMQ4223)
D 1 "Tail wheel (GPMQ4241)
D (2) 3/32" Wheel collars (GPMQ4302)
D 12" Medium fuel tubing (GPMQ4131)
D (2) Rolls covering film
D 1/4" Foam Rubber (HCAQ1000)

4. You must properly install all R/C and other components
so that the model operates correctly on the ground and in
the air

5 You must test the operation of the model before every

flight to insure that all equipment is operating, and you must

make certain that the model has remained structurally

sound Be sure to check clevises or other connectors often
and replace them if they show signs of wear or fatigue

NOTE: We, as the kit manufacturer, provide you with a

top quality kit and great instructions but ultimately the
quality of your finished model depends on how you build

it, therefore, we cannot in any way guarantee

the performance of your completed model, and no

representations are expressed or implied as to the

performance or safety of your completed model

Remember: Take your time and follow directions to end
up with a well-built model that is straight and true.
Please inspect all parts carefully before starting to build!

YOU CAN CONTACT US...

If any parts are missing, broken or defective, or if you
have any questions about building or flying this

airplane, please call us at (217) 398-8970. You can also
check our web site at www.greatplanes.com for the
latest Gee Bee updates, or e-mail your questions to

[email protected]. If you are calling for
replacement parts, please reference the part numbers

and the kit identification number (stamped on the end of

the carton) and have them ready when calling.

These are the building supplies that are required We

recommend Great Planes Pro" CA and Epoxy glue

D 1 oz ThinCA(GPMR6002)
D 1 oz Medium CA (GPMR6008)
D 6-Minute Pro Epoxy (GPMR6045)
D 30-Minute Pro Epoxy (GPMR6047)
D Balsa filler (HCAR3401)

D Masking Tape (TOPR8018)
D Plan Protector (GPMR6167)
D IsopropyI Rubbing Alcohol (70%)

D Sanding block and sandpaper (coarse, medium, tine)
D Hobby knife (HCAR0105)
D #11 blades (HCAR0311)
D Single edge razor blades (HCAR0212)
D Razor Saw
D Razor Plane

D Electric drill
D Drill bits - 1/16", 5/64", 7/64", 1/8",

3/32",3/16"(HCAR0699)

D Small Phillips and flat blade screwdrivers
D Pliers with wire cutter
D Sealing Iron (COVR2700)
D Heat Gun (TOPR2000)
D T-Pins (HCAR5150)

D Straightedge with scale (HCAR0475)
D Cutting Mat (HCAR0456)
D Builders Triangle (HCAR0480)

3
