For Customer Service, contact the place of purchase to arrange for replacement parts.
Fixture Name:
8201-M1L BLK/SLV
PARTS & ASSEMBLY SHEET (
cont.)
G
H
I
J
F
3. Pull the fixture’s wires through the Rods.
4. Thread Rod (J) into Frame (K) until tight.
5. Thread Rod (I) into Rod (J) until tight. repeat for any
additional rods.
6. Feed the fixture wires through the Canopy (G) and
pull the wires until taut.
7. Thread Canopy (G) into Rod (H) until tight.
* You may now install the fixture.
Note: Complete these remaining steps after the
fixture is hung.
8. Slide the Shade (N) on the Socket(M) and secure by
screwing tightly the Socket ring (L)and(U).
9. Install the light bulbs in accordance with the
fixture's specification.
10. Hang the crystals
(DO NOT EXCEED MAXIMUM WATTAGE RATING!)
