For Customer Service, contact the place of purchase to arrange for replacement parts.
PARTS & ASSEMBLY SHEET (cont.)
Fixture Name: Wynn 3082-M3/6/8 PW
Fig. 2
7. Slip Canopy loop collar (H) over the chain, then do the
same with the canopy (G).
8. When ready to complete the installation Use the other
chain connector and attach the other end of the chain to
the canopy loop (F) and close the chain connector.
9. Make sure the weight of the chandelier will be supported
by the chain-not the electrical wire.
* You may now install the fixture.
ASSEMBLING THE FIXTURE (Fig. 2)
4. Measure to determine the correct number of links
needed for proper hanging height. Use a pair of
pliers to open one link of Chain (K) then remove
the excess chain and discard it.
5. Use Chain Connector (L) to attach one end of
the chain to the Top loop (J). Then, close the chain
connector.
6. Feed the fixture wires through every three links of
chain and pull the wires until taut.
7. Slip Canopy Loop Collar (H) over the chain, then
do the same with the Canopy (G).
8. To complete the installation, use the other
chain connector and attach the other end of
the chain to Canopy Loop (F) and close the
chain connector.
9. Make sure the weight of the chandelier will be
supported by the chain, not the electrical wire.
* You may now install the fixture.
Note: Complete these remaining steps after the
fixture is hung.
10. Install the light bulbs (not provided) in
accordance with the fixture's specifications.
(DO NOT EXCEED MAXIMUM WATTAGE RATING)
R
Q
I
N
P
G
C
D
K
L
H
F
J
