PA G E 1 0 I n s t r u c t I o n m A n uA l
W 1
3. rotate the
Channel
selector or press
the or keys to toggle between
‘WcHnl’ (channel selector) or
‘WscAn’ (scan/Priority) functions.
4. Press and hold
Menu
(or wait for the
menu function to time-out) to store
your setting and exit the menu.
USINg ThE ChANNEL
SELECTOR OPTION
Briefly press the
left
key to select a
lower channel or the
right
key to select
a higher channel.
Press and hold the
left
key to quickly step downwards through the channels
or the
right
key to quickly step upwards. release the key to stop.
USINg ThE SCAN/PRIORITy OPTION
Briefly press the
left
key to start or stop scanning. Press and hold the
left
key
to add or remove the currently selected channel from the scan memory.
Briefly press the
right
key to switch immediately to the priority channel. Press
and hold the
right
key to store the currently selected channel as the
priority channel.
SPECIFICATIONS
Electrical
compliant specification: meets As/nZs 4268:2008 for short range devices
Frequency range tX: 2.4 GHz
operating temperature: -10°c to 60°c
current consumption: 2 uA on standby, 12 mA on transmit
rF output: 4 dBm
Battery type: cr2025
Mechanical
Dimensions: 40 mm diameter x 14 mm (h)
Weight: 12 grams
scan/Priority opti on (WscAn)
Ptt
Priority (store)
scan (memory)
