SUPPLIED wIth
tX3510S tX3520S tX3540S
tX3510s radio tX3520s radio tX3540s radio
mounting cradle
microphone tX3520s remote Head
mounting cradle mounting cradle
controller microphone
microphone clip microphone microphone Extension lead
Dc lead microphone clip 8 Pin to 8 Pin Adapter
screw Pack Dc lead microphone clip
Instruction manual connecting cable Dc lead
screw Pack screw Pack
Instruction manual Instruction manual
scanning .................................................................13
open scan ...............................................................14
Group scan .............................................................15
network scan ..........................................................16
ctcss and Dcs .......................................................18
selective calling ......................................................20
using selcall ...........................................................20
responding to selcall Alert ......................................22
Quiet mode .............................................................22
Group calling ..........................................................24
receive-only channels .............................................25
configuration menu ................................................29
InstAllAtIon ................................................................30
General ...................................................................30
tX3510s and tX3540s Installation ..........................30
tX3520s Installation ...............................................31
microphone .............................................................31
Dc Power connection ..............................................32
AntEnnA connEctIon ................................................33
noIsE suPPrEssIon .......................................................33
wiring .....................................................................34
ctcss tonE FrEQuEncY cHArt ....................................35
Dcs tonE cHArt............................................................36
uHF cB oPErAtInG FrEQuEncIEs .................................37
sPEcIFIcAtIons .............................................................38
sc contrAct wArrAntY AGAInst DEFEcts ................39
CONtENtS
INtrODUCtION
Your GmE tX3510s/tX3520s/tX3540s 80 channel radio
is Australian designed and built and is the most advanced
uHF citizen Band radio available. It combines the very latest
in electronic hardware with the most up-to-date computer
aided design and manufacturing techniques to produce
an extremely compact mobile radio with outstanding
specifications and performance.
Your radio is designed for unobtrusive mounting in modern
vehicles. with its built-in loud speaker and extremely small
size, it can be mounted in almost any convenient location.
IMPOrtANt INFOrMAtION
CONCErNING UhF CB rADIO
the use of the citizen Band radio service is licensed in
Australia by the AcmA radio communications (citizens
Band radio stations) class licence and in new Zealand by
the ministry of Economic Development new Zealand (mED).
A General user radio licence for citizens Band radio
and operation is subject to conditions contained in those
licences.
the class licence for users and equipment operating in the
cB/Prs 477 mHz band has been amended. this radio meets
the new 80 channel standard.
In simple terms the same amount of spectrum is available;
however, radio transceivers can now operate in a narrower
bandwidth and hence use less spectrum. these radios are
generally referred to as narrowband or 12.5 kHz radios. By
using 12.5 kHz channel spacing instead of 25 kHz, the 40
channels originally allocated can now be expanded to 80
channels thereby doubling the channel capacity and relieving
congestion in the uHF cB/Prs band.
original 40 channel wideband radios will continue to operate
on the original 40 channels, however they will not be able
to converse on the newer channels 41 – 80. the newer
narrowband radios will be able to converse with all older 40
channel wideband radios on all channels 1 to 40 as well as the
newer channels allocated from 41 to 80.
the mixing of narrowband and wideband radios in the same
spectrum can cause some possible operating issues
of interference and varying levels of received volume.
