INStALLAtION
GENErAL
Your radio is supplied with a slim, slide on mounting cradle.
As the radio contains a built-in speaker, the cradle can be
screwed or bolted to any convenient location in your vehicle’s
cabin (under or above the dash or on the centre console)
using the mounting slots provided in the cradle.
In the case of the remote mount tX3520s, the remote head
can be installed in a convenient location inside the cabin
allowing the main unit to be hidden away under the seat, in
the glove box or even in the boot if required. In this case an
extension speaker will also be required.
when planning your installation, avoid locations that are
close to heaters or air conditioners.
tX3510S AND tX3540S INStALLAtION
For maximum sound projection from the internal speaker,
we recommend the cradle be mounted above the radio to
minimise any obstruction of the speaker. Alternatively, if it
is necessary to mount the unit in a less audible location, an
extension speaker can used. the extension speaker plugs into
the extension speaker socket on the radio’s rear panel.
Console Mounting
A flush mounting DIn adapter mBD001 is available as an
optional accessory. the adapter includes mounting brackets
and a specially designed front panel escutcheon to suit most
vehicle installations. see your nearest GmE retailer for details.
Din Adapter mBD001
installing the Cradle
screw the mounting cradle to a firm surface then slide the
radio’s main unit into the cradle from the front until it clicks
into place. Finally, connect the power lead, antenna cable and
extension speaker (if required) to the sockets on the radio’s
rear panel.
Mounting the Cradle
Fitting the radio
slide radio fully into cradle until it clicks into place.
removing the radio
tX3520S INStALLAtION
the tX3520s remote head can be installed inside the cabin
with the main unit hidden away in the glove box, under the
seat or in the boot. Install the remote head bracket into a
convenient location near your driving position using screws
or double sided tape. loosen the gimbal controls and slide
the remote head into the slots in the bracket. Adjust the
remote head for the desired angle then tighten the controls.
the mounting of the main unit is identical to that of the
tX3510s and tX3540s models. If the main unit is installed in
a remote location, you will also need to install an extension
speaker inside the cabin. the extension speaker plugs into the
extension speaker socket on the rear panel of the main unit.
CHANNEL
remote Head
main unit
Option 1
Option 2
