PA G E 3 8 I n s t r u c t I o n m A n uA l t X 3 5 1 0 s / t X 3 5 2 0 s / t X 3 5 4 0 s t X 3 5 1 0 s / t X 3 5 2 0 s / t X 3 5 4 0 s I n s t r u c t I o n m A n uA l PA G E 3 9
transmit Frequency
response: +6 dB per octave
300 Hz to 3 kHz + 1–3 dB.
Demodulated Audio
signal to noise: >45 dB unweighted
current consumption: 1.7 amps with 50 ohms
termination.
receiver
Intermediate Frequencies: 38.85 mHz, 450 kHz
sensitivity: -122 dBm for 12 dB
sInAD unweighted
selectivity: -6 dB at + 3.5 kHz
-60 dB at ± 12.5 kHz
Intermodulation
Immunity: -72 dB
Blocking Immunity: -98 dB
spurious response
Immunity: 70 dB
Audio output Power: 3 watts average into 4 ohms
Audio signal to noise: >45 dB unweighted
receive Frequency
response: -6 dB/octave de-emphasis
300 Hz to 3 kHz + 1–3 dB.
current consumption: <175 mA muted
750 mA full volume.
conducted spurious
Emission: <70 dBm
MEChANICAL SPECIFICAtIONS & CONNECtIONS
Dimensions: 29 (H) x 128 (l) x 117 (D) mm
weight: 450 grams
12 Volt Power supply: two core cable with bulkhead
connector in rear panel.
Antenna: so239 panel socket
External speaker: 3.5 mm mono jack
microphone Port: 6 way telephone style
with rubber strain relief.
specifications are subject to change without notice or obligation
this warranty against defects is given by standard communications
Pty ltd Acn 000 346 814 (we, us, our or GmE). our contact details
are set out in clause 2.7.
1. Consumer guarantees
1.1 our goods come with guarantees that cannot be excluded
under the Australian consumer law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
1.2 to the extent we are able, we exclude all other conditions,
warranties and obligations which would otherwise be implied.
2. Warranty against defects
2.1 this warranty is in addition to and does not limit, exclude or
restrict your rights under the competition and consumer Act
2010 (Australia) or any other mandatory protection laws that
may apply.
2.2 we warrant our goods to be free from defects in materials
and workmanship for the warranty period (see warranty table)
from the date of original sale (or another period we agree to
in writing). subject to our obligations under clause 1.2, we
will at our option, either repair or replace goods which we
are satisfied are defective. we warrant any replacement parts
for the remainder of the period of warranty for the goods into
which they are incorporated.
2.3 to the extent permitted by law, our sole liability for breach
of a condition, warranty or other obligation implied by law is
limited
(a) in the case of goods we supply, to any one of the
following as we decide –
(i) the replacement of the goods or the supply of
equivalent goods;
(ii) the repair of the goods;
(iii) the cost of repairing the goods or of acquiring
equivalent goods;
(b) in the case of services we supply, to any one of the
following as we decide –
(i) the supplying of the services again;
(ii) the cost of having the services supplied again.
2.4 For repairs outside the warranty period, we warrant our repairs
to be free from defects in materials and workmanship for three
months from the date of the original repair. we agree to
re-repair or replace (at our option) any materials or workmanship
which we are satisfied are defective.
2.5 we warrant that we will perform services with reasonable care
and skill and agree to investigate any complaint regarding
our services made in good faith. If we are satisfied that the
complaint is justified, and as our sole liability to you under this
warranty (to the extent permitted at law), we agree to supply
those services again at no extra charge to you.
2.6 to make a warranty claim you must before the end of the
applicable warranty period (see warranty table), at your own
cost, return the goods you allege are defective, provide written
details of the defect, and give us an original or copy of the
sales invoice or some other evidence showing details of
the transaction.
2.7 send your claim to: standard communications Pty ltd.
Po Box 96 winston Hills, nsw 2153, Australia.
tel: (02) 8867 6000 Fax: (02) 8867 6199
Email: [email protected]
2.8 If we determine that your goods are defective, we will pay for
the cost of returning the repaired or replaced goods to you,
and reimburse you for your reasonable expenses of sending
your warranty claim to us.
3. What this warranty does not cover
3.1 this warranty will not apply in relation to:
(a) goods modified or altered in any way;
(b) defects and damage caused by use with non standard
communications products;
(c) repairs performed other than by our authorised
representative;
(d) defects or damage resulting from misuse, accident,
impact or neglect;
(e) goods improperly installed or used in a manner contrary
to the relevant instruction manual; or
(f) goods where the serial number has been removed or
made illegal.
4. Warranty period
4.1 we provide the following warranty on GmE and Kingray
products. no repair or replacement during the warranty period
will renew or extend the warranty period past the period from
original date of purchase.
StANDArD COMMUNICAtIONS CONtrACt wArrANty AGAINSt DEFECtS
PrODUCT TyPE
WarraNTy
PEriOD
All fixed mount ‘s’ model uHF cB radios 5 years
