In completion of Step 4, Motor Carrier should be as
shown:
Step 5:
Place plastic washer on axel as shown.
Step 6:
Place wheel on axel as shown.
Secure with pin.
**Bend pin to secure in place**
Step 7:
Place caps on wheels. Gently tap into place with
hammer.
***Step 8: Tighten all fasteners on carrier.***
Finished Assembly:
Maintenance:
Periodically lubricate wheels and polish** aluminum to
ensure a long life.
NOTE: Recommended for 1-15 h.p./85 lb. motors. For
motors over 5 h.p., mount board on back side of
handle tubes.
**EEz-In marine polish, Model 65010, available.
Plastic Washer
Axel
