Garelick 15730 DOCK/RAFT LADDER - Manual (Page 2)

(2) CHANNEL
M
(4) NYLON
WASHER
H
VRT 3
R
4 STEP VERTICALS
(4 STEP MODEL ONLY)
5 STEP VERTICALS
(5 STEP MODEL ONLY)
(2) HAIR PIN
J
PPH 1/4 X 2" SELF TAPPING
(18) 3 STEP, (24) 4 STEP, (30) 5 STEP
C
VRT 1
P
(4) CAP
E
(4) HINGE
PLATE
N
VRT 2
Q
(8) 1/4-20 NUT
D
(2) VELCRO
STRAP
G
(4) PLUG
F
(2) CLEVIS PIN
I
PARTS LIST FOR
FOLDING DOCK/RAFT PONTOON LADDER
Form 12.549
Write for
a Complete
Catalog
644 2nd Street, PO Box 8
St. Paul Park, Minnesota 55071
Phone: 651-459-9795
E-mail: [email protected]
Website: www. garelick.com
07/05
(6) PPH 1/4-20 X 2-1/4
B
VRT 4
S
(2) PPH 1/4-20 X 1-3/4
A
STEP
(3) 3 STEP MODEL
(4) 4 STEP MODEL
(5) 5 STEP MODEL
O
(2) VERTICAL
ASSEMBLY
K
(2) HAND RAIL
L
