(2) PIT HOVERING/PIT-TRIM
• HOVERING PITCH trims the pitch setting near the center (hover) point on the T/C stick. Adjustment is
possible without changing the High or Low pitch limits.
• PITCH TRIM makes parallel shifting of the pitch curve possible without changing the shape of the curve.
Setting Method (PIT HOVERING)
1) Select the EDIT screen and move the cursor
to Line 2 with the cursor key, the press the
Setting Method (PIT-TRIM)
1) Move the cursor to the PIT-TRIM line with
the cursor
key
and
press the
program key.
2) Select the PITCH screen by pressing the
3) To change the Hovering Pitch value, move the
program key, then press the
key again to
select the PIT HOVERING screen.
cursor to the RATE line with the
cursor key and set the rate with the
program key. The high and low
pitch limits will remain the same.
program key. The PITCH TRIM position is
displayed in ( ).
2) The CH7 Knob becomes the Pitch Trim Con-
trol and normal CH7 use is deactivated. A
buzzer sounds at the neutral (PIT-TRIM = 0)
position.
3) The CH7 Knob trim authority can be adjusted
by moving the cursor to the LEVER line and
using the
program keys.
4) The Hovering Pitch can be trimmed using the
Hovering Pitch Trim Lever on the left side of
the transmitter. The hovering pitch rate,
including the trim lever amount is displayed in
( ) on the RATE line. A buzzer sounds when
the trim lever is moved to the center position.
5) Trim lever authority can be adjusted by mov-
ing the cursor to the LEVER line and using
the program
keys.
6) To activate the Hovering Pitch function, move
the cursor to the ACT/I NH position and press
the program
key.
To
deactivate, press
the
key.
4) To deactivate Pitch Trim, move the cursor to
the PIT-TRIM line and press the
program
key.
5) To return to the PITCH screen, press the
program key.
Adjustable
within
this range
