ADJUSTMENTS AND FLIGHT TECHNIQUES
PARAMETER
1) Servo Test: Each servo is operated in linear
fashion from neutral, to its maximum and
minimum positions. The operation is repeated
sequentially for Channels 1 through 8.
2) M i x i n g Mode: In the BASIC mode, all of the
special mixing circuits except Programmable
Mixing are deactivated. BASIC or HELI oper-
ating mode can be selected.
3) PCM/PPM: PCM or PPM encoding can be
selected with this function. PPM encoding
allows the transmitter to be used with stan-
dard FM receivers.
4) D/R SW D I R : The ON/OFF directions of the
D/R Switches can be selected. In Mode 1, the
upper position is the D/R ON (Low Rate)
position, and in Mode 2, the lower position is
the ON position.
5) COMBI SW: The function of the CH5 switch
can be selected from among Rudder D/R,
Rudder Offset, and Idle-Up 1.
Setting Method
1) Select the EDIT screen and move the cursor
to Line 2 with the cursor key,
then display the PARAMETER screen by
pressing the program
key.
6) Combi Switch:
1. Move the cursor to the COMBI SW position
using the cursor key and acti-
vate or deactivate the function with the
2) Servo Test: Move the cursor to the SERVO-
TES position with the cursor
key. Turn the function ON and OFF with the
program keys.
'ACT and INH program keys.
2. Designate the CH5 Switch or the AUX.
CH8 switch as the COMBI switch with the
program key.
3) MIX-MODE: Move the cursor to the MIX- 3. Move the cursor to the MIX position with
MODE position with the cursor
key. Select either the BASIC or HELI mixing
mode by pressing the program
key.
4) PCM/PPM: M.ove the cursor to the PCM/PPM
position and select the desired encoding
method by pressing the program
key.
NOTE: The encoding will NOT change until
the transmitter power switch is turned OFF
and back ON again.
5) Dual Rate Switch Direction: Move the cursor
the cursor key. To use IDLE-
UP1, press the soft key and to use
rudder offset, press the soft key.
When nothing is used, press the soft
key.
4. Move the cursor to the D/R position with
the cursor key and select if
rudder D/R is deactivated or activated
when the COMBI switch is turned on with
the soft
keys.
7) Return to the EDIT screen by pressing the
soft key.
to the D/R SW DIR position and select Mode
1 or Mode 2 with the program
key.
