ADJUSTMENTS AND FLIGHT TECHNIQUES
• A bar graph along the lower edge of the display
indicates the corresponding T/C stick position.
1) Move the standard cursor to the POINT posi-
tion using the cursor key.
2) Select the graph point to be adjusted with the
cursor key. The points are
numbered 1 through 12 from left to right on
the graph.
When Pitch Curves Are Not Used
1) To deactivate the pitch curve function, move
the cursor to the ACT/INH position of the
PITCH CURVE screen using the cursor keys,
and press the program key.
2) When the pitch curves are deactivated, the
Hovering Pitch lever on the left side of the
transmitter becomes the CH6 control lever.
3) The Point Cursor is designated by a "+" sym-
bol on the graph. The point number selected
will be displayed in ( ) next to the standard
cursor and the Point Cursor (+) will be located
at that point on the graph.
4) The selected point can be raised or lowered
Inverted Pitch Setting
1) Move the cursor to the upper left corner of
the PITCH CURVE screen and select the
INVERT function by pressing the pro-
gram key.
by pressing the program key. The
curve can be returned to normal (linear) from
by pressing the key.
5) The rate set at each point will be displayed
inside the standard cursor.
Curve Copy Function
• Refinements in the Pitch Curve shape that were
made using the "Point Cursor" method can be
transfered from one curve to another. High
and Low Pitch limits set at the HI and LO
position lines will not transfer. Therefore, the
curve being set will become similar in shape to
the curve being copied although it will not be
identical unless the HI and LO limits are the
same on both curves.
Setting Method
1) Move the cursor to the POINT line of the
PITCH CURVE screen with the
cursor key.
2) Press the
FROM" will be displayed on the POINT line.
3) Select the curve to be copied by pressing the
program key.
4) Copying of the POINT settings is now com-
pleted, and the graph on the right will display
a curve more similar (or identical) to the curve
that was copied.
program key. The word "COPY
2) Move the cursor to the INH/ACT position at
the top of the screen and press the pro-
gram key.
3) The CH5 switch is the INVERT ON/OFF
Switch.
4) The INVERT curve does not have a Point
Cursor Setting function. The NORMAL pitch
curve is used as the pitch curve.
5) The maximum LOW and HIGH pitch limits
can be set the same as the other curves. There
is no sub-trimmer for the INVERT Low pitch
adjustment. The High Pitch limit can be
trimmed with the High Pitch Trim Lever
(lever throw can be adjusted in the same
manner as with the other curves). The "LO"
and "HI" settings made on the INVERT
screen will affect the pitch limits only at
INVERT ON position of the CH5 switch.
6) The low pitch limits (crossover) can be ad-
justed for both the NORMAL and INVERT
curves simultaneously, by moving the cursor
to the INV-TRIM line and adjusting the limits
using the
program keys.
7) Return to the EDIT screen by pressing the
program key.
NOTE: Pitch mixing cannot be used in the
BASIC mixing mode. (See PARAMETERS ON
page 46).
5) Return to the original % display by pressing
the key.
