LDU 78.1 Technical Manual, Rev. 12 May 2011 Page 28 of 36
8.11. Save Calibration and Setup Data Commands – CS, WP, SS, GI, PI
The calibration and setup parameters can be divided in 3 groups:

Calibration : CM, DS, DP, CZ, CG, ZT, IZ and FD, saved by command CS

Setup : FL, FM, NR, NT, BR, AD, DX and other, saved by command WP

Setpoints: S0, S1, H0, H1, A0, A1, saved by command SS
Note: Calibration data can only be saved if the TAC code is known and precedes the CS command. See the
CE and CS commands in chapter 8.2.
The setup data and the setpoint data will be stored non-volatile in the EEPROM using the WP respective SS
command.
8.11.1. WP Save the Setup Parameters
With this command the settings of the “Filter” (FL, FM) ,the “No-motion” (NR, NT) and the communication (AD,
BR, DX) will saved in the EEPROM.
Master (PC / SPS) sends Slave (LDU XX.X) responds Meaning
WP  OK Setup data saved
WP
 ERR Error
8.11.2. SS Save Setpoint Parameters
With this command the setpoints (S0, S1), the setpoint hysteresis (H0, H1) and the setpoint allocation (A0, A1)
will be saved in the EEPROM.
Master (PC / SPS) sends Slave (LDU XX.X) responds Meaning
SS  OK Setpoint parameters saved
SS  ERR Error
8.11.3. GI Save an Image File from the EEPROM
Saves a HEX-INTEL formatted EEPROM image file from the source LDU’s EEPROM. The image file contains
all stored information except the calibration data. This image file can be downloaded to any LDU with the same
firmware type and revision no. as the source LDU.
8.11.4. PI Download an Image File to the EEPROM
Downloads a HEX-INTEL formatted EEPROM image file to the target LDU’s EEPROM. The image file contains
all stored information except the calibration data.
Attention: The target LDU must have same firmware type and revision no. as the source LDU.
