LDU 78.1 Technical Manual, Rev. 12 May 2011

Page 12 of 36

7.

Commands – Overview

Command Short

description

Parameter

value

Page

AD

Communication: Device Address

0...255

27

A n

Setpoints: Output of Gros (0) or Net (1) for setpoints S0 and S1

0 or 1

26

BR

Communication: Baud Rate

9600…115200 baud 27

CE

Calibration: Open Calibration Sequence; Read TAC Counter

0...65535

15

CG

Calibration: Set Calibration Gain (Span) at Load > Zero

0...99999 d

16

CI

Calibration: Minimum Output Value

–99999...0 d

15

CL

Communication: Close Device

None

27

CM n

Calibration: Set Maximum Output Value (n = 1, 2 or 3)

1...99999 d

15

CS

Save the Calibration Data (CM, CI, DS, DP, etc.) to the EEPROM

None

18, 28

CZ

Calibration: Set Calibration Zero Point – Scale Without Load

None

16

DP

Calibration: Set Decimal Point Position

0...5

16

DS

Calibration: Set Display Step Size

1, 2, 5, 10, …, 200 d 16

DT

Trigger function: Calculation Time for Short-time Average

0...65535 ms

31

DX

Communication: Set Half-duplex (0) or Full-duplex (1)

0 or 1

27

FD

Factory default settings: Write Data to the EEPROM (TAC protected)

None

17

FM

Digital filter: Filter Mode

0 or 1

19

FL

Digital filter: Filter Cut-off Frequency

0...7

19

GA

Output: Get Triggered Average Value

None

22, 29

GG

Output: Get Gross Value

None

22

GI

Saves an image file from the LDU’s EEPROM

None

28

GL

Output: Get Data String “Average/Gross/Status“

None

23

GN

Output: Get Net Value

None

22

GS

Output: Get ADC Sample Value

None

22

GT

Output: Get Tare Value

None

22

GW

Output: Get Data String “Net/Gross/Status“

None

22

H n

Setpoints: Hysteresis for Setpoint S0 (H0) or S1 (H1)

-99999...+99999 d

26

HT

Trigger function: Hold time for Violation of Setpoint Limit

0...65535 ms

32

ID

Device information: Identify Device

None

14

IM

Digital output: Enable Output for External Control

0000...0011

25

IN

Digital input: Input Status

None

25

IO

Digital output: Output Status

0000...0011

25

IS

Device information: Identify Device Status

None

14

IV

Device information: Identify Firmware Version

None

14

IZ

Calibration: Correction of System Zero

None

17

MR

Calibration: Define Multi-interval (0) or Multi-range (1)

0 or 1

15

MT

Trigger function: Measuring Time for Averaging

0...500 ms

29

NR

Motion detection: No-motion Range

0...65535 d

18

NT

Motion detection: No-motion Time Period

0...65535 ms

18

OF

Output: Format of Data String Output

0…3

23

OP

Communication: Open Device xxx

0...255

27

PI

Download a saved image file to the LDU’s EEPROM

None

28

RS

Device information: Read serial number

None

14

RT

Scale function: Reset Tare and Switch to Gross Indication

None

21

RW

Trigger function: Trigger Window for Re-trigger Function

0...65535 d

21, 31

RZ

Scale function: Reset Zero Point

None

21

SA

Auto-transmit: Send Triggered Average Value automatically

None

27, 30

SD

Trigger function: Start Delay

0...500 ms

29

SG

Auto-transmit: Send Gross Value continuously

None

24
