LDU 78.1 Technical Manual, Rev. 12 May 2011 Page 11 of 36
6. Calibration and Calibration Sequence
The calibration of LDU 78.1 is only possible after starting a calibration sequence (compare with chapter 8.2).
 Command CE: Calibration enable – returns the current TAC value
 Command CM1 / CM2 /CM3: Calibrate maximum display – sets the max. allowable display value
 Command CI: Calibrate minimum – sets the minimum allowable display value
 Command MR: Multi-range / Multi-interval
 Command DS: Display step size – sets the output incremental step size
 Command DP: Decimal point – sets the position of the output decimal point
 Command CZ: Calibrate zero – sets the system zero point
 Command CG: Calibrate gain – sets the system gain
 Command ZT: Zero track enable / disable
 Command IZ: If applicable: Correction of System Zero
 Command ZR: If applicable: Zero Range – sets the zero range manually
 Command ZI: If applicable: Initial Zero Range
 Command WT: If applicable: Warm-up time
 Command FD : If applicable: Reset to factory default settings
 Command CS : Save calibration data (TAC counter automatically incremented by 1)
Preparing the calibration:
 Check, if the max value of the display is set sufficiently high (see chapter 8.2: command CM n)
 Check, if the no motion conditions are defined reasonable (chapter 8.3: e.g. NR = 1, NT = 1000)
 Set the IIR filter frequency to 0.5 Hz (see chapter 8.4: FM = 0, FL = 7)
Example:
Setup of zero point, system gain and decimal point
The chosen calibration weight has the value 5000 (increments). That could be 500 g, 5 kg or 5000 kg. We
calibrate with 500 g. The decimal point is set up by command DPx (x = 1, 2 or 3), here 1 figure after the
decimal point. A measured weight of 500 g is displayed as 500.0.
Master (PC / SPS) sends Slave (LDU XX.X) responds Meaning
CE
 E+00017
(example) Request: TAC counter CE17
Adjust zero: The scale has to be empty. No load!
CE 17  OK Calibration sequence active
CZ
 OK System zero point saved
Adjust gain: First put the calibration weight on the scale (here 500 g)!
CE 17  OK Calibration sequence active
CG 5000  OK Setting span
CG
 G+05000 Request: span 5000 d
CE 17  OK Calibration sequence active
DP 1  OK Setting: decimal point 0000.0
CE 17
 OK Calibration sequence active
CS  OK Save calibration data in EEPROM
Zero point, gain and decimal point position were saved in the EEPROM; the calibration counter (TAC) is
increased automatically by 1.
