LDU 78.1 Technical Manual, Rev. 12 May 2011

Page 20 of 36

8.4.3. UR Update Rate and Averaging

Depending on the selected filter mode this command defines an averaging for the output value. The permitted
settings are from 0 to 7 (see table below

). The average value will always be calculated from

2

UR

measurement

values.

LDU 78.1 allows for following settings:

UR

0

1

2

3

4

5

6

7

Measurement values / second

1

2

4

8

16

32

64

128

Check / Setup of the averaging:

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

UR

U+0001

Request: Averaging of 2 values

UR 4

OK

Setup: Averaging of 16 values

WP

OK

Setup saved


Default setting: 0 (no averaging, output rate = 600 values / second)

Update rate in Mode 1:

UR

Output rate (values/s)

FL0

FL1

19.7 Hz

FL2

9.8 Hz

FL3

6.5 Hz

FL4

4.9 Hz

FL5

3.9 Hz

FL6

3.2 Hz

FL7

2.8 Hz

FL8

2.5 Hz

0

600 600 300 200 150 120 100 85.7 75

1

300 300 150 100 75 60 50 42.85

37.5

2

150 150 75 50 37.5 30 25 21.42

18.75

3 75 75 37,5 25 18.75 15 12.5 10.71 9.38
4 37.5 37,5 18.75 12.5 9.38 7.5 6.25 5.36 4.69
5

18.75 18.75 9.38 6.25 4.69 3.75 3.13 2.68 2.34

6

9.38 9.38 4.69 3.13 2.34 1.88 1.56 1.34 1.17

7

4.69 4.69 2.34 1.56 1.17 0.94 0.78 0.67 0.59
