background image

LDU 78.1 Technical Manual, Rev. 12 May 2011

Page 17 of 36

8.2.10. FD

Reset to Factory Default Settings

This command puts the LDU back to a known state. The data will be written to the EEPROM and the TAC will
be incremented by 1.

Note:

All calibration and setup information will be lost by issuing this command!

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

CE

E+00017

(example)

Request: TAC counter CE17

CE 17

OK

Calibration sequence active

FD

OK

Factory default setting

8.2.11. IZ

Correction of System Zero

This command can correct the system zero after a successful calibration, e.g. to correct the unknown weight of
a mounting accessoiry which was used to hold the calibration weight during the calibration procedure. By a
simple parallel shift of the gain curve the sensitivity of the scale will stay unaffected.

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

CE

E+00017

(example)

Request: TAC counter CE17

CE 17

OK

Calibration sequence active

IZ

OK

System zero corrected

8.2.12. ZR

Zero Range

Sets the zero range manually – this is the range in increments within which the weighing scale can be zeroed.
Issuing the ZR command without any parameter will return the current value. Permitted values are between the
lower limit of 0 (= factory default setting) and the upper limit of 99999. A value of zero enables the standard
zero range of +/-2% of max.

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

CE

E+00017

(example)

Request: TAC counter CE17

CE 17

OK

Calibration sequence active

ZR 100

OK

Setup: Zero range = 100 d

8.2.13. ZI

Initial Zero Range

Defines the initial zero range (0…99999 d). If ZI is non-zero the device will perform an automatic Set-Zero
when the weight stabilizes with the No-motion settings and the weight is within the ZI range. Factory default: 0.

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

CE

E+00017

(example)

Request: TAC counter CE17

CE 17

OK

Calibration sequence active

ZI 100

OK

Setup: Initial Zero range = 100 d

8.2.14. WT Warm-up time

Sets the warm up time – this command defines a time interval between 0 (= factory default setting) and 65535 s
after power on where the output value will be set to “uuuuuuu” to avoid false readings during the initial
stabilisation period.

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

CE

E+00017

(example)

Request: TAC counter CE17

CE 17

OK

Calibration sequence active

WT 20

OK

Setup: Warm-up time = 20 s

8.2.15. TM Tare mode

This commands sets the tare mode to R76 compatible (TM = 1: tare values < 0 not allowed; default setting) or
user-defined (TM = 0; any tare value is allowed).

Master (PC / SPS) sends

Slave (LDU XX.X) responds

Meaning

CE

E+00017

(example)

Request: TAC counter CE17

CE 17

OK

Calibration sequence active

TM 1

OK

Setup: Tare mode = 1
