EN

14

FZS 3020-B

ATTENTION: Hold the brush cutter fi rmly with both hands. Always stand so that your body is on the left of
the shaft tube. Never hold the handle with crossed arms. These instructions also apply to left-handers.

ATTENTION: Exposure to vibrations may damage the health of persons that suffer from circulatory or
nerve system problems. If any physical problems become evident, such as desensitisation, loss of sensitivity,
loss of usual strength or changes in skin colour, please contact a doctor.
These systems usually manifest themselves on fi ngers, hands or wrists.

PROCEDURES FOR STARTING AND STOPPING THE ENGINE

Starting a cold engine

1. Set the power switch to the "START" position.

(see fi g. 8)

2. Repeatedly push down the fuel primer bulb

(5 to 10 presses), until the fuel gets to the
carburettor. (see fi g. 9)

3. Move the choke lever upwards to the "OFF"

position (=air supply turned off, i.e. choke turned
on). (see fi g. 9)

4. Lean the brush cutter against the ground so that

it is stable and pull on the handle of the starting
cord until the engine rotates (the engine will show
signs of attempting to start).

5. At this point, push the choke lever downwards to

the "ON" position (=air supply turned on, i.e. choke
turned off) and start the engine by repeatedly
pulling on the starting cord.

ATTENTION! Spinning the engine for too long

with the choke lever in the OFF position will result
in fl ooding of the engine and problems with
starting it up.

6. Prior to starting work, leave the engine to warm

up for a few minutes to get up to operating
temperature.

Starting a warm engine

1. Set the power switch to the "START" position.
2. Pull on the handle of the starting cord until the

engine starts up. DO NOT USE THE CHOKE!

Starting the brush cutter

Fig. 9

Fuel primer
bulb

Choke control lever

Fig. 8

Safety
throttle safety switch

Throttle
lever

Power switch
