A p p e n d i x B
CHRISTIE DIGITAL SYSTEMS M35GPS Projector B-21
March, 2004
12 Ball Bearing, by-pass Roller Assembly 598931-119
13 Roller, Film by-pass Sound Head 119168-001
14 External Retaining Ring 598931-154
15 Analog LED Assembly 196049-001
16 Screw, SHC 6-32 x 1/2 598931-042
17 Sound Drum-Shaft (DS, LED) 194798-001
18 Airpot - Snubber 598931-783
19 Dashpot Bracket, Sound Head 119160-001
20 Flat Washer #6 515819-275
21 Flat Split Lock Washer #6 515819-201
22 Screw, SHC 6-32 x 3/8 598931-041
23 Shaft, Lateral Guide Roller 119162-001
24 Bearing, Lateral Guide Roller 598931-124
25 Roller, Lateral Guide, Sound Head 119164-001
26 Shim Spacer 598931-438
27 Washer – Wave Spring 598931-439
28 Upper Arm, Block – Stabilizer 196183-001
29 Lower Arm, Block-Stabilizer 196183-002
30 Lateral Guide Roller Assembly 121312-001
31 Spring, Sound Head Sub Assembly 598931-145
32 LED Solar Cell Assy. 196212-002
33 Shaft, Arm Sound Head 196185-001
34 Shim Spacer, .020 THK. 598931-064
35 Mount, Bracket LED Reader 196224-001
36 Spacer, Bearing, Analog / Digital 196210-001
37 Spring Anchor 196205-001
38 Shim Spacer, .010 THK. (Optional) 598931-063
39 Analog Reader Assy. 196179-002
40 Screw, Socket Head Cap 8-32 x 5/8” 515500-100
41 Screw, 8-32 x ½” 598931-044
42 O-ring, 1
½”
ID x 1-5/8” OD x 1/16 598931-097
Table B-12: Central Pivot Analog Soundhead Assembly Parts List
