A p p e n d i x A
CHRISTIE DIGITAL SYSTEMS P35GPS Projector A-1
March, 2004
A P P E N D I X A : R E P L A C E A B L E A S S E M B L I E S A N D
C O M P O N E N T S
Part Number Description Section
119263-002 Dowser Blade Assembly 5.4.6
119450-005 Ultramittent Assembly 5.4.6
120651M001 Ultramittent Shoe Closure Assembly 5.4.6
120660-001 Band for Trap and Gate 5.4.1
121117-003 Standard Aperture Plate
121195-001 Electric Changeover Assembly 5.4.9
121205-001 Electric Changeover Coil 5.4.6
121330-001 Cooling Fan 5.4.12
196555-001 Turret Assembly (Automatic) 5.4.6
121435-001 Aperture Drive Assembly (Automatic) 5.4.6
196260-001 LED Sound-head Assembly (Central Pivot) 5.4.7
196556-001 Trap and Gate Assembly, Automatic 5.4.1
194697-001 Single Blade Shutter Assembly 5.4.10
194768-001 Motor Assembly – 60 Hz 5.4.11
194768-002 Motor Assembly – 50 Hz 5.4.11
194810-001 Jackshaft Assembly 5.4.6
194818-001 Pulley, 30-Groove (Ultramittent)
194824-001 Jackshaft pulley, 16-Grove (Single Blade) 5.4.10
194825-001 Motor Pulley, 24-Groove (60 Hz) 5.4.11
194825-002 Motor Pulley, 29-Groove (50 Hz) 5.4.11
194827-001 Shutter Driver Pulley, 12-Groove 5.4.10
194834-001 Digital Power Supply Assembly
194852-001 LED Sound-head Assembly 5.4.7
194856-001 Upper Constant-Speed Sprocket Assembly 5.4.5
194856-002 Center Constant-Speed Sprocket Assembly 5.4.5
194857-001 Lower Constant-Speed Sprocket Assembly 5.4.5
Table A-1: P35GPS Projector Replaceable Assemblies and Components
