CHRISTIE DIGITAL SYSTEMS P35GPS Projector
March, 2004
2-1
2 . G E N E R A L D E S C R I P T I O N
The CHRISTIE P35GPS Projector, manufactured exclusively by CHRISTIE DIGITAL
SYSTEMS in Cypress, California, is a dual-lens 35mm movie projector that employs a
revolutionary sealed-bearing intermittent movement called the Ultramittent©. This
movement coupled with uncompromising design and assembly workmanship, results in the
finest possible theater picture reproduction. The Ultramittent movement is standard on all
CHRISTIE projectors.
2.1. O
P T I O N A L
F
E A T U R E S
Options available for enhancing the standard features of the P35GPS projector include:
• manual dual-lens turret
• automatic dual or triple lens turret, including automatic aperture changer
• inboard Dolby digital reader
• all models available in 50 Hz or 60 Hz
2.2. S
P E C I F I C A T I O N S
Standard specifications for the P35GPS projector family are listed in the Table shown in
Figure 2-1, below.
POWER REQUIREMENTS:
Input Voltage 115 VAC, 5 Amp, 60 Hz
OR 220 VAC, 3 Amp, 50 Hz
DIMENSIONS:
Height 23 inches
Width 18 inches
Depth 16 inches
WEIGHT : Standard: approximately 90 lb.
FILM SPEED: Standard: 24 frames/sec (90 ft/min)
OPERATING TEMPERATURE: 0 to +45°C
MOTOR: Synchronous split phase, 1800 rpm, 60 Hz
OR 1500 rpm, 50 Hz
Figure 2-1: Table of Equipment Specifications
These specifications may vary slightly, depending upon the particular model and options
chosen.
