CHRISTIE DIGITAL SYSTEMS P35GPS Projector B-14
March, 2004
# Item Description Part Number
1 Screw, Truss, 10-32 x 0.375 in (0.9525 cm) L (2) 598931-486
2 Sprocket, Film 598931-107
3 Shaft, Lower Constant Speed Sprocket 194833-001
4 Screw, SHC, 4-40 x 0.25 in (0.635 cm) L 598931-038
5 Stripper 119107-001
6 Post, Stripper 119106-001
7 Housing, Sprocket 119103-001
8 Screw, SHC, 10-32 x 1.5 in (3.81 cm) L 598931-195
9 Screw, Socket (2) 515500-070
10 Clip, Spring Retainer 196219-001
11 Base Stud, Arm Toggle 119112-001
12 Sleeve, Bearing (2) 598931-090
13 Screw, SHC, 8-32 x 0.625 in (1.5875 cm) L (3) 598931-045
14 Pad Roller, Delrin® 598931-762
15 Bearing, 0.5 in ID x 0.8750 in OD x 0.2812 in THK (2) 598931-636
16 Square Key, 0.28125 in (0.714375 cm) L (2) 119073-003
17 Shaft, Pad Roller, Stud Assembly 598931-116
18 Screw, Allen, Hex Socket Set, Steel 119078-001
19 Roller Arm, Pad 119102-001
20 Screw, Set, Hex, 8-32 x 0.1875 in (0.47625 cm) L (3) 598931-023
21 Square Key, 0.1875 in (0.47625 cm) L 119073-001
22 Shaft, Pad Roller Arm 119109-001
23 Shaft Spacer (2) 598931-062
24 Toggle Stud, House 119112-002
25 Spring, Compression 598931-141
26 Toggle Arm 119104-001
27 Pulley, 45-Groove 194858-002
28 Stop, Pad Roller Arm 119054-001
29 Insert, Locking Screw 598931-194
30 Washer, Lock, #4 598931-209
31 Washer, Plated Flat, #4, Constant Speed 598931-427
32 Screw, SHC, 10-32 x 0.625 in (1.5875 cm) L 598931-049
33 Washer, Wave (2) 598931-192
34 Pulley, Lower 119111-001
35 Knob, Turndown 194510-001
36 Screw, Head, C-Sink,82°, 10-32 x 0.75 in (1.905 cm) L (2) 515500-429
37 Shim Spacer 598931-066
Table B-7: Lower Constant-Speed Sprocket Assembly (P/N 194857-001)
