Digilent Digilab 2 - Manual (Page 8)

Digilent Digilab 2 Reference Manual Digilent, Inc.
www.digilentinc.com page 8 of 10
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
Table 2. Digilab 2 Expansion Connector pinouts
A&E connector B&F connector C connector D connector
Pin Signal S-II pin Pin Signal S-II pin Pin Signal S-II pin Pin Signal S-II pin
1 GND - 1 GND - 1 GND - 1 GND -
2 VU - 2 VU - 2 VU - 2 VU -
3 VDD33 - 3 VDD33 - 3 VDD33 - 3 VDD33 -
4 A4 70 4 B4 194 4 C4 181 4 D4 127
5 A5 69 5 B5 193 5 C5 180 5 D5 125
6 A6 68 6 B6 192 6 C6 179 6 D6 126
7 A7 67 7 B7 191 7 C7 178 7 D7 122
8 A8 63 8 B8 189 8 C8 176 8 D8 123
9 A9 62 9 B9 188 9 C9 175 9 D9 120
10 A10 61 10 B10 187 10 C10 174 10 D10 121
11 A11 60 11 B11 185* 11 C11 173 11 D11 115
12 A12 59 12 B12 182* 12 C12 172 12 D12 119
13 A13 58 13 B13 - 13 C13 168 13 D13 113
14 A14 57 14 B14 - 14 C14 167 14 D14 114
15 A15 49 15 B15 - 15 C15 166 15 D15 111
16 A16 48 16 B16 - 16 C16 165 16 D16 112
17 A17 47 17 B17 - 17 C17 164 17 D17 109
18 A18 46 18 NC - 18 C18 163 18 D18 110
19 A19 45 19 NC - 19 C19 162 19 D19 102
20 A20 44 20 NC - 20 C20 161 20 D20 108
21 A21 43 21 NC - 21 C21 160 21 D21 100
22 A22 42 22 NC - 22 C22 154 22 D22 101
23 A23 41 23 NC - 23 C23 152 23 D23 98
24 A24 37 24 NC - 24 C24 151 24 D24 99
25 A25 36 25 NC - 25 C25 150 25 D25 96
26 A26 35 26 NC - 26 C26 149 26 D26 97
27 A27 34 27 NC - 27 C27 148 27 D27 94
28 A28 33 28 NC - 28 C28 147 28 D28 95
29 A29 31 29 NC - 29 C29 146 29 D29 89
30 A30 30 30 NC - 30 C30 142 30 D30 90
31 A31 29 31 NC - 31 C31 141 31 D31 87
32 A32 27 32 NC - 32 C32 140 32 D32 88
33 A33 24 33 NC - 33 C33 139 33 D33 84
34 A34 23 34 NC - 34 C34 138 34 D34 86
35 A35 22 35 NC - 35 C35 136 35 D35 82
36 A36 21 36 NC - 36 C36 135 36 D36 83
37 A37 20 37 NC - 37 C37 134 37 D37 75
38 A38 18 38 NC - 38 C38 133 38 D38 81
39 A39 17 39 NC - 39 C39 132 39 D39 73
40 A40 16 40 NC - 40 C40 129 40 D40 74
* uses GCLK pin
