Digilent 32MX7 User Manual
Page 19
Cerebot 32MX7 Reference Manual
www.digilentinc.com
page 19 of 19
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
JPF
Any of the Pmod connectors can provide either regulated or unregulated power. To use
regulated power, place the jumper block over the center pin and the pin marked 3V3. To use
unregulated power, place the jumper block over the center pin and the pin marked 5V0.
