Cerebot 32MX7 Reference Manual

www.digilentinc.com

page 11 of 19

Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.

Appendix B: Connector and Jumper Block Pinout Tables

MCU Port Bit to Pmod Connector Pin

MCU
Port Bit

Signal

Connector
Pin

Notes

RA00

TMS/RA0

JF-07

RA01

TCK/RA1

JF-08

RA02

SCL2/RA2

N/A

I2C Bus #2, not shared with Pmod connector

RA03

SDA2/RA3

N/A

I2C Bus #2, not shared with Pmod connector

RA04

TDI/RA4

JF-09

RA05

TDO/RA5

JF-10

RA06

TRCLK/RA6

JE-07

RA07

TRD3/RA7

JE-08

RA09

Vref-/CVref-/AERXD2/PMA7/RA9

JE-09

RA10

Vref+/CVref+/AERXD3/PMA6/RA10

JE-10

RA14

AETXCLK/SCL1/INT3/RA14

N/A

I2C Bus #1, not shared with Pmod connector

RA15

AETXEN/SDA1/INT4/RA15

N/A

I2C Bus #1, not shared with Pmod connector

RB00

PGED1/AN0/CN2/RB0

N/A

Used by debug circuit, PGC

RB01

PGEC1/AN1/CN3/RB1

N/A

Used by debug circuit, PGD

RB02

AN2/C2IN-/CN4/RB2

JA-01

RB03

AN3/C2IN+/CN5/RB3

JA-02

RB04

AN4/C1IN-/CN6/RB4

JA-03

RB05

AN5/C1IN+/VBUSON/CN7/RB5

N/A

USB VBUSON

RB06

PGEC2/AN6/OCFA/RB6

JA-04

RB07

PGED2/AN7/RB7

JA-07

RB08

AN8/C1OUT/RB8

JA-08

RB09

AN9/C2OUT/RB9

JA-09

RB10

CVrefout/PMA13/AN10/RB10

JA-10

RB11

AN11/ERXERR/AETXERR/PMA12/RB11

N/A

Ethernet PHY

RB12

AN12/ERXD0/AECRS/PMA11/RB12

N/A

Ethernet PHY

RB13

AN13/ERXD1/AECOL/PMA10/RB13

N/A

Ethernet PHY

RB14

AN14/ERXD2/AETXD3/PMALH/PMA1/RB14

JC-10

RB15

AN15/…/OCFB/PMALL/PMA0/CN12/RB15

JC-07

RC01

T2CK/RC1

JC-01

RC02

T3CK/AC2TX/RC2

N/A

CAN2 Transceiver

RC03

T4CK/AC2RX/RC3

N/A

CAN2 Transceiver

RC04

T5CK/SDI1/RC4

JD-03

RC12

OSC1/CLKI/RC12

N/A

Primary Oscillator Crystal

RC13

SOSCI/CN1/RC13

N/A

Secondary Oscillator Crystal

RC14

SOSCO/T1CK/CN0/RC14

N/A

Secondary Oscillator Crystal

RC15

OSC2/CLKO/RC15

N/A

Primary Oscillator Crystal

RD00

SDO1/OC1/INT0/RD0

JD-02

RD01

OC2/RD1

JD-07

RD02

OC3/RD2

JD-08

RD03

OC4/RD3

JD-09

RD04

OC5/PMWR/CN13/RD4

JC-09

RD05

PMRD/CN14/RD5

JC-08

RD06

ETXEN/PMD14/CN15/RD6

N/A

Ethernet PHY

RD07

ETXCLK/PMD15/CN16/RD7

JC-04

RD08

RTCC/EMDIO/AEMDIO/IC1/RD8

N/A

Ethernet PHY
