Table 3: HDMI Connector Pin Layouts
JAA
Pin
Pinout
1
VCC5V0
2
VCCB
3
JA-D2_P
4
GND
5
JA-D2_N
6
JA-D1_P
7
GND
8
JA-D1_N
9
JA-D0_P
10
GND
11
JA-D0_N
12
JA-CLK_P
13
GND
14
JA-CLK_N
15
VCCB
16
GND
17
JE2/SCL
18
JE1/SDA
19
VCC5V0
JBB
Pin
Pinout
1
VCC5V0
2
VCCB
3
JB-D2_P
4
GND
5
JB-D2_N
6
JB-D1_P
7
GND
8
JB-D1_N
9
JB-D0_P
10
GND
11
JB-D0_N
12
JB-CLK_P
13
GND
14
JB-CLK_N
15
VCCB
16
GND
17
JE2/SCL
18
JE1/SDA
19
VCC5V0
NOTE: All signals are connected via a 50 ohm
resistor
JCC
Pin
Pinout
1
VCC5V0
2
VCCB
3
JC-D2_P
4
GND
5
JC-D2_N
6
JC-D1_P
7
GND
8
JC-D1_N
9
JC-D0_P
10
GND
11
JC-D0_N
12
JC-CLK_P
13
GND
14
JC-CLK_N
15
VCCB
16
GND
17
JE2/SCL
18
JE1/SDA
19
VCC5V0
JDD
Pin
Pinout
1
VCC5V0
2
VCCB
3
JD-D2_P
4
GND
5
JD-D2_N
6
JD-D1_P
7
GND
8
JD-D1_N
9
JD-D0_P
10
GND
11
JD-D0_N
12
JD-CLK_P
13
GND
14
JD-CLK_N
15
VCCB
16
GND
17
JE2/SCL
18
JE1/SDA
19
VCC5V0
