VmodMIB Reference Manual
www.digilentinc.com page 3 of 5
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
Table 1: VHDCI Signals and Connector Pinout
J1
1 JC-CLK_P 35 JC-CLK_N
2 GND 36 GND
3 JC-D0_P 37 JC-D0_N
4 JC-D1_P 38 JC-D1_N
5 GND 39 GND
6 JC-D2_P 40 JC-D2_N
7 JA-D0_P 41 JA-D0_N
8 GND 42 GND
9 JA-D1_P 43 JA-D1_N
10 JA-D2_P 44 JA-D2_N
11 GND 45 GND
12 JB-D0_P 46 JB-D0_N
13 JB-D1_P 47 JB-D1_N
14 GND 48 GND
15 JA-CLK_P 49 JA-CLK_N
16 VCCB 50 VCCB
17 VCC5V0 51 VCC5V0
18 VCC5V0 52 VCC5V0
19 VCCB 53 VCCB
20 JB-CLK_P 54 JB-CLK_N
21 GND 55 GND
22 JB-D2_P 56 JB-D2_N
23 JE8 57 JE7
24 GND 58 GND
25 JE2/SCL 59 JE1/SDA
26 JE10 60 JE9
27 GND 61 GND
28 JE4 62 JE3
29 JD-CLK_P 63 JD-CLK_N
30 GND 64 GND
31 JD-D0_P 65 JD-D0_N
32 JD-D1_P 66 JD-D1_N
33 GND 67 GND
34 JD-D2_P 68 JD-D2_N
S1 SHIELD S2 SHIELD
