DPCUTIL Programmer’s Manual
www.digilentinc.com
© Digilent, Inc. Page 9 of 14
rgbSend[0]
TMS 4 TDI 4 TMS 3 TDI 3 TMS 2 TDI 2 TMS 1 TDI 1
rgbSend[1]
MS 8 TDI 8 TMS 7 TDI 7 TMS 6 TDI 6 TMS 5 TDI 5
If fReturnTdo is set to true, all bits
shifted out are stored in rgbRcv Tdo.
Each bit is shifted out sequentially
starting at the first element in the
rgbRcv, from lowest significant bit to
most significant bit. TMS is held at the
value specified by bitTms while bits are
being shifted into TDI.
BOOL DpcPutTmsTdiBits(HANDLE hif, int cbit,
BYTE * rgbSnd, BOOL fReturnTdo, BYTE *
rgbRcv, ERC * perc, TRID * ptrid)
Parameters
hif
- handle to JTAG
interface
cbit
- number of TMS
and TDI bit pairs sent.
rgbSnd - buffer that holds
TMS and TDI bit pairs.
fReturnTdo
- specifies if bits
from TDO should be returned
rgbRcv
- (optional) holds
shifted out TDO bits. Only used if
fReturnTdo is true.
perc
- pointer to store
error code
ptrid
- pointer to store
transaction ID. If ptrid is NULL, this
function will be
blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
Shifts a specified number of bits into
TMS and TDI and (optionally) returns
bits shifted out of TDO. RgbSend holds
TMS and TDI bit pairs. Each bit pair is
shifted in sequentially; starting at the
first element in the array, from least
significant bit pair to most significant bit
pair. In each pair, the TMS value is the
MSB and the TDI value is the LSB.
Below is an example of how the
TMS/TDI bit pairs are placed in each
byte of rgbSend.
If fReturnTdo is set to true, all bits
shifted out are stored in rgbRcv Tdo.
Each bit is shifted out sequentially
starting at the first element in the
rgbRcv, from lowest significant bit to
most significant bit.
BOOL DpcGetTdoBits(HANDLE hif, int cbits,
BOOL bitTdi, BOOL bitTms, BYTE *rgbRcv,
ERC *perc, TRID *ptrid)
Parameters
hif
- handle to JTAG
interface
cbit
- number of TMS
and TDI bits to push onto the JTAG
TAP controller
bitTdi
- value TDI pin will
be held at (true = 1, false = 0)
bitTms
- value TMS pin
will be held at (true = 1, false = 0)
rgbRcv
- holds shifted out
TDO bits.
perc
- pointer to store
error code
ptrid
- pointer to store
transaction ID. If ptrid is NULL, this
function will be
blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
