Digilent, Inc TM
DPCUTIL Programmer’s Manual
www.digilentinc.com
© Digilent, Inc. Page 12 of 14
rgbData[0], the data byte in the register
specified by the address in rgbAddr[1]
is written to rgbData[1], etc.
BOOL DpcPutRegRepeat(HANDLE hif, BYTE
bAddr, BYTE * rgbData, int cbData, ERC *
perc,
TRID * ptrid)
Parameters
hif
- handle to Data
interface
bAddr
- address of
register to send stream of data bytes
rgbData
- buffer with data
bytes to be sent to address
cbData
- number of bytes
to be sent
perc
- pointer to
store error code
ptrid
- pointer to
store transaction ID. If ptrid is NULL,
this function will be
blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
Sends a stream of data bytes to a
single, specified register address.
BAddr is a register address that will be
sent many bytes one at a time in
sequential order. RgbData is a buffer
containing the data that will be sent to
bAddr. The will be sent as quickly as
the Digilent Communications Interface
Module will allow. The number of bytes
to be sent to bAddr is specified in
cbData.
BOOL DpcGetRegRepeat (HANDLE hif, BYTE
bAddr, BYTE * rgbData, int cbData, ERC *
perc,
TRID * ptrid)
Parameters
hif
- handle to Data
interface
bAddr
- address of
register to send stream of data bytes
rgbData - buffer to store
data bytes from address
cbData
- number of
bytes to be received from address
perc
- pointer to
store error code
ptrid
- pointer to
store transaction ID. If ptrid is NULL,
this function will be
blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
Gets a stream of data bytes from a
single, specified register address.
RgbData is a buffer that will contain
data read out of the register at address
bAddr. The data is read as quickly as
the Digilent Communications Interface
Module will allow. The number of bytes
to be read out of bAddr is specified in
cbData.
API Device Manager calls
void DvmgStartConfigureDevices(HWND
hwnd, ERC *perc)
Parameters
hwnd
- handle to parent
window
perc
- pointer to store
error code
Return Values
none
Description
Opens the Device Table dialog box.
This dialog box is used to add, remove,
or modify communication modules in
the device table.
int DvmgGetDevCount(ERC *perc)
Parameters
perc
- pointer to store
error code
Return Values
