BOOL DpcGetReg(HANDLE hif, BYTE
bAddr, BYTE * pbData, ERC * perc, TRID *
ptrid)
Parameters
hif
- handle to Data
interface
bAddr
- address of
register to read Data byte
pbData
- pointer to store
data byte read
perc
- pointer to store
error code
ptrid
- pointer to store
transaction ID. If ptrid is NULL, this
function will be blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
Gets a single data byte from a register
specified by its address.
BOOL DpcPutRegSet(HANDLE hif, BYTE *
rgbAddr, BYTE * rgbData, int cbData, ERC *
perc,
TRID * ptrid)
Parameters
Hif
- handle to
Data interface
rgbAddr
- addresses of
registers to write Data bytes
rgbData
- buffer with data
bytes to be sent
cbData
- number of bytes
to be sent
perc
- pointer to store
error code
ptrid
- pointer to store
transaction ID. If ptrid is NULL, this
function will be
blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
Sends many data bytes to many
specified addresses. RgbAddr is a
buffer containing addresses of
registers. RgbData is a buffer
containing data that will be sent to the
corresponding addresses. Each
element in the rgbData buffer is written
to the corresponding address in the
rgbAddr buffer. For example, the data
byte in rgbData[0] is written to the
register address in rgbAddr[0], the data
byte in rgbData[1] is written to the
register address in rgbAddr[1], etc.
BOOL DpcGetRegSet(HANDLE hif, BYTE *
rgbAddr, BYTE * rgbData, int cbData, ERC *
perc,
TRID * ptrid)
Parameters
hif
- handle to Data
interface
rgbAddr
- addresses of
registers to read Data bytes
rgbData
- buffer to store
data bytes read
cbData
- number of bytes
to be sent
perc
- pointer to store
error code
ptrid
- pointer to store
transaction ID. If ptrid is NULL, this
function will be
blocking.
Return Values
Returns true if successful. Returns
false otherwise.
Description
Gets many data bytes from many
specified addresses. RgbAddr is a
buffer containing addresses of
registers. RgbData is a buffer that will
contain data recieved from the registers
specified by the addresses in rgbAddr.
Each element in the rgbData buffer is
read from the corresponding address in
the rgbAddr buffer. For example, the
data byte in the register specified by
the address in rgbAddr[0] is written to
