Carrier 38GXC - Manual (Page 27)

27
A3 -- CHARACTERISTICS OF TEMPERATURE SENSORS
Temperature
° F (° C)
Indoor Outdoor
Return Air Coil Coil OD Air Comp. Discharge
10 (---12.2) 92220 123000 123000 92220 306200
50 (10.0) 29900 39870 39870 29900 98000
90 (32.2) 11090 14790 14790 11090 36380
130 (54.4) 4625 6167 6167 4625 15170
190 (87.8) 1497 1996 1996 1497 4904
230 (110.0) 758 1010 1010 758 2498
A4 -- PRESSURE -- TEMPERATURE CHART
Cooling
Ambient Temp. ° F
9K 12K
Suction Pressure Discharge Temp. Suction Pressure Discharge Temp.
82 115 --- 125 96 --- 98 125 --- 135 102 --- 104
95 130 --- 140 108 --- 110 140 --- 150 114 --- 116
125 170 --- 180 134 --- 136 165 --- 175 132 --- 134
Heating
Ambient Temp. ° F
9K 12K
Suction Pressure Discharge Temp. Suction Pressure Discharge Temp.
47 100 --- 110 124 --- 126 105 ---115 124 --- 126
65 165 --- 175 138 --- 140 170 --- 180 138 --- 140
