25
A1 -- CONTROL BOARDS INPUT OR OUTPUT VALUES
INDOOR BOARD
CONNECTOR VOLTAGE
INPUT DATA1 BLACK(24v max) relative to N DC
INPUT N BLUE (neutral)
INPUT AC L1: BROWN(115v) relative to N AC
OUTPUT FAN1:
[Pin1 BLACK (0---115v) Pin2:GREEN(0---115v) Pin3:YELLOW(0---115v) Pin5:BROWN(0---115v)
Pin6:RED(0---115v)] relative to Pin4:WHITE
INPUT X2: [PIN1:BULE 115v AC relative to PIN2: YELLOW
OUTPUT X1: [Pin1 YELLOW(13±2v AC) relative to Pin2:YELLOW][ Pin3:WHITE(8±2v AC) relative to Pin4:WHITE]
OUTPUT X3:
[Pin1 BLUE(0---12v) Pin2:PINK(0---12v) Pin3:YELLOW(0---12v) Pin4:ORANGE(0---12v) Pin5:RED(12v)] relative to
heat sink (X101) DC
OUTPUT X9: Multiple Pins (6 PATH) Any Pin (0---12v DC ) relative to heat sink (X101)
OUTPUT X12: Multiple Pins (7 PATH)(0---12v DC) relative to heat sink (X101)
INPUT X9 MK1: PIN1:BLACK (0---5V DC) relative to PIN2:YELLOW
INPUT X13: PIN1:BLACK (0---5V DC) relative to PIN2:YELLOW
OUTDOOR BOARD
CONNECTOR VOLTAGE
INPUT X1 BLACK(0---24v DC) relative to X2
INPUT X2 WHITE(neutral)
INPUT X3 RED(115v AC) relative to X2
OUTPUT X5 BROWN(115v) relative to X2
OUTPUT X4 GROUND
INPUT CN3 PIN1: WHITE 0---3.3v DC relative to PIN2
INPUT CN2 PIN1: BLACK 0---3.3v DC relative to PIN2
INPUT CN1 PIN1: Yellow 0---3.3v DC relative to PIN2
OUTPUT X8 BLUE (115v AC) relative to X18
OUTPUT X18 BLUE(neutral)
INPUT CN4 PIN1: RED 0---3.3v DC relative to PIN2
INPUT CN7 PIN2:BLACK 12v DC PIN3:BLACK 18v DC all relative to PIN1: BLACK
OUTPUT CN8 PIN2:BLACK 12v DC PIN3:BLACK 18v DC all relative to PIN1: BLACK
OUTPUT CN6 U:WHITE 100±50v AC V:ORANGE 100±50v AC relative to W:RED
OUTPUT U(X11) U:WHITE 100±50v AC) relative to W:RED
OUTPUT V(X12) V:ORANGE 100±50v AC relative to W:RED
OUTPUT X17 BLUE(neutral)
OUTPUT X9 BROWN 250±50v AC relative to X15
OUTPUT X6 BLUE(neutral)
OUTPUT X15 BLUE(neutral)
OUTPUT X10 BLUE 250±50v AC relative to X15
OUTPUT X16 BLUE 250±50v AC relative to X15
OUTPUT X7 BROWN(neutal)
OUTPUT X14 RED 0---115v AC relative to X7
OUTPUT X21 BLACK 0---115v AC relative to X7
