Toshiba FS-160 SERIES User Manual
Page 42
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
Table 5.1 PS Output Voltage
Symbol
Voltage (V)
Supplied to:
Note
+5V
+4.75^+5.25
ICs
-5V
-4.5—5.5
Display control IC
-VD
-38--46
Display tube grids
VF1,VF2
AC4.5/V6.5
Display tube filaments
Effective value
BATTERY
+2.4V min.
RAM/ timer (at power
failure time)
RAM holding voltage
(28 pin voltage):
2.0V min.
VM
AC22'^26
Printer, drawer, buzzer
Effective value
(TYP: 24V)
-25-
