NOTES:
In the "VDP AUTO" mode, when an LD with the Dolby Digital AC~3 audio is detected, the decoder switches automatically and the Dolby Digital
AC-3 audio is played. Also, in any mode other than normal LD player playback, no Dolby Digital AC-3 signals are detected, so the mode automatical­
ly switches to PCM or analog audio.
In the "VDP AUTO" mode, when the mode changes from pause, chapter search, etc., to playback during playback of the Dolby Digital AC-3 audio
on an LD, the PCM or analog sound may be output momentarily before the mode is switched to the Dolby Digital AC-3 audio mode.
If this happens, the sound will not be interrupted if you switch to the "VDP AC-3RF" (AC-3RF fixed input) mode.
The AC-3.RF input mode setting is reset to "VDP AUTO" when the power is turned off using the power switch on the remote control unit or on
the main unit.
b. Digital input
Select the digital input. Refer to page 23, 8-3, 1,2 and 3.
2. Set the Dolby Surround mode.
Lights
3. Play a program source with the o TTTTTT l mark or a
program source with Dolby Digital AC-3 formats.
The indicators below showing the signals included in the software
light, (The number of channels differs according to the software.)
Lights ■
t
-0-
c R
L: Front Left ch SL: Surround Left ch
SL SR
C: Center ch S; Mono Surround ch
R: Front Right ch SR; Surround Right ch
j (This only lights wheit the surround signals
I------are monaural.)
Also, the following indicator lights if the software contains Low Fre­
quency Effect sounds;
LFE
------------- - Lights
4-1. Adjust the sound for the program source using the on screen dis­
play,
4-2. Press the ENTER button.
4-3, Use the CURSOR buttons to specify "Surround Parameters''
(screen 24)
,4-4. Press the ENTER button to switch the screen.
5, Use the CURSOR buttons to move the cursor on the screen and set
the parameters, (screen 25)
CURSOR CURSOR
©
A
CURSOR ev
6, After the above settings are completed, press the ENTER button.
Menu
System Setup
A
crSurround Parameters
^ Tuner Preset Stations
Menu Off
screen 24 )
I De fay it ] Y e s i
screen 25 )
NOTES:
« With the this model, Dolby Digital AC-3 encoded signals can only be played in the Dolby Pro Logic, Dolby Digital AC-3, direct and stereo
modes. Other surround mode buttons will not function during the Dolby Digital AC-3 signal playback,
e When the mode is switched to Dolby Digital AC-3 encoded signals while playing PCM digital signals or analog signals in the MONO,5CH STEREO,
SUPER STADIUM, ROCK ARENA, JAZZ CLUB, CLASSIC CONCERT or MATRIX Surround mode, the mode is forcibly switched to the Dolby
Surround mode.
29
